718419-YTG-D-0613
Johnson Controls Unitary Products 33
BHQ060 (5.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1450
77 62.5 3.4 62.5 62.5 62.5 - - - 66.3 3.8 66.3 63.1 57.3 - - -
72 59.2 3.3 59.2 59.2 59.2 59.2 - - 60.9 3.7 60.0 54.2 48.3 42.5 - -
67 55.8 3.3 54.2 48.5 42.8 37.1 31.4 - 55.6 3.7 51.1 45.3 39.4 33.6 27.7 -
62 50.0 3.2 50.0 50.0 50.0 44.5 38.8 33.1 49.6 3.6 49.6 49.6 46.5 40.7 34.8 29.0
1500
77 65.0 3.4 65.0 65.0 65.0 - - - 67.1 3.8 69.8 63.7 57.7 - - -
72 61.4 3.3 61.4 61.4 61.4 61.4 - - 61.7 3.7 60.8 54.7 48.7 42.6 - -
67 57.8 3.3 54.5 48.5 42.6 36.6 30.6 - 56.2 3.7 51.8 45.8 39.7 33.6 27.6 -
62 51.7 3.2 51.7 51.7 49.9 43.9 37.9 32.0 50.2 3.6 50.2 50.2 46.9 40.8 34.8 28.7
57 52.8 3.2 52.8 52.8 52.8 49.9 44.0 38.0 49.8 3.6 49.8 49.8 49.8 43.8 37.7 31.6
1550
77 67.4 3.4 67.4 67.4 67.4 - - - 67.9 3.8 67.9 64.4 58.1 - - -
72 63.6 3.3 63.6 63.6 63.6 62.6 - - 62.4 3.7 61.6 55.3 49.0 42.8 - -
67 59.8 3.3 54.8 48.6 42.3 36.0 29.8 - 56.9 3.7 52.5 46.3 40.0 33.7 27.5 -
62 53.5 3.2 53.5 53.5 49.6 43.4 37.1 30.8 50.8 3.6 50.8 50.8 47.2 40.9 34.7 28.4
57 54.6 3.2 54.6 54.6 54.6 49.9 43.6 37.3 50.4 3.6 50.4 50.4 50.4 44.1 37.9 31.6
1600
77 69.8 3.4 69.8 69.8 69.8 - - - 68.6 3.8 68.6 65.0 58.5 - - -
72 65.8 3.3 65.8 65.8 65.8 62.4 - - 63.1 3.7 62.3 55.9 49.4 42.9 - -
67 61.8 3.3 55.1 48.6 42.1 35.5 29.0 - 57.5 3.7 53.2 46.8 40.3 33.8 27.3 -
62 55.3 3.2 55.3 55.3 49.3 42.8 36.2 29.7 51.3 3.7 51.3 51.3 47.5 41.1 34.6 28.1
57 56.3 3.2 56.3 56.3 56.3 49.8 43.2 36.7 51.0 3.6 51.0 51.0 51.0 44.5 38.0 31.6
1800
72 68.4 3.3 68.4 68.4 68.4 65.7 - - 65.1 3.7 64.7 59.8 52.4 45.1 - -
67 64.2 3.3 60.9 52.0 44.6 37.2 29.8 - 59.3 3.7 57.2 50.1 42.8 35.4 28.1 -
62 57.4 3.2 57.4 57.4 53.3 45.9 38.5 31.1 53.0 3.7 53.0 53.0 50.5 43.1 35.8 28.5
57 58.5 3.2 58.5 58.5 58.5 51.1 43.7 36.3 52.6 3.6 52.6 52.6 52.6 45.2 37.9 30.6
2000
72 71.0 3.3 71.0 71.0 71.0 69.1 - - 67.0 3.7 67.0 63.7 55.5 47.3 - -
67 66.6 3.3 66.6 55.5 47.2 38.9 30.7 - 61.1 3.7 61.1 53.4 45.2 37.1 28.9 -
62 59.6 3.2 59.6 59.6 57.3 49.0 40.7 32.5 54.6 3.7 54.6 54.6 53.4 45.2 37.0 28.8
57 60.6 3.2 60.6 60.6 60.6 52.4 44.1 35.8 54.2 3.6 54.2 54.2 54.2 46.0 37.8 29.6
95°F 105°F
1450
77 70.0 4.2 31.9 25.9 19.9 - - - 59.8 4.7 28.2 22.6 16.8 - - -
72 62.7 4.1 39.9 34.0 28.0 22.0 - - 54.7 4.7 37.0 31.2 25.4 19.6 - -
67 55.4 4.1 48.0 42.0 36.0 30.0 24.1 - 49.6 4.6 45.9 39.8 34.0 28.2 22.4 -
62 49.2 4.1 49.2 49.2 42.8 36.8 30.9 24.9 44.2 4.6 44.2 44.2 39.9 34.1 28.2 22.4
1500
77 69.2 4.2 32.6 26.5 20.4 - - - 59.6 4.7 29.5 23.2 17.2 - - -
72 61.9 4.1 40.9 34.7 28.6 22.5 - - 54.5 4.7 38.1 32.0 26.0 20.0 - -
67 54.7 4.1 49.1 43.0 36.9 30.7 24.6 - 49.4 4.6 46.6 40.9 34.9 28.9 22.9 -
62 48.6 4.1 48.6 48.6 43.8 37.7 31.6 25.4 44.1 4.6 44.1 44.1 40.9 34.9 28.9 22.9
57 46.8 4.0 46.8 46.8 43.7 37.6 31.4 25.3 43.3 4.6 43.3 43.3 41.0 35.0 29.0 23.0
1550
77 68.3 4.2 33.4 27.1 20.8 - - - 59.4 4.7 30.7 23.8 17.6 - - -
72 61.2 4.2 41.8 35.5 29.3 23.0 - - 54.3 4.7 39.1 32.9 26.7 20.5 - -
67 54.0 4.1 50.2 43.9 37.7 31.4 25.2 - 49.3 4.6 47.4 42.0 35.8 29.6 23.4 -
62 48.0 4.1 48.0 48.0 44.8 38.5 32.3 26.0 44.0 4.6 44.0 44.0 42.0 35.8 29.6 23.4
57 46.2 4.0 46.2 46.2 44.7 38.4 32.1 25.9 43.2 4.6 43.2 43.2 42.0 35.9 29.7 23.5
1600
77 67.5 4.2 34.1 27.7 21.3 - - - 59.2 4.7 32.0 24.4 18.0 - - -
72 60.4 4.2 42.7 36.3 29.9 23.5 - - 54.1 4.7 40.1 33.7 27.4 21.0 - -
67 53.3 4.1 51.3 44.9 38.5 32.1 25.7 - 49.1 4.6 48.1 43.0 36.7 30.3 24.0 -
62 47.4 4.1 47.4 47.4 45.8 39.4 33.0 26.6 43.8 4.6 43.8 43.8 43.0 36.7 30.3 24.0
57 45.6 4.1 45.6 45.6 45.6 39.2 32.8 26.4 43.1 4.6 43.1 43.1 43.1 36.7 30.4 24.0
1800
72 61.7 4.2 46.3 39.0 31.8 24.5 - - 55.2 4.7 43.5 36.3 29.0 21.8 - -
67 54.5 4.1 53.5 48.2 40.9 33.6 26.4 - 50.1 4.6 49.6 46.0 38.9 31.7 24.5 -
62 48.5 4.1 48.5 48.5 47.7 40.4 33.1 25.9 44.7 4.6 44.7 44.7 44.3 37.1 29.9 22.7
57 46.7 4.1 46.7 46.7 46.7 39.4 32.1 24.9 43.9 4.6 43.9 43.9 43.9 36.7 29.5 22.3
2000
72 63.1 4.2 49.8 41.7 33.6 25.5 - - 56.3 4.7 46.9 38.8 30.7 22.7 - -
67 55.7 4.1 55.7 51.4 43.3 35.2 27.0 - 51.1 4.6 51.1 48.9 41.2 33.1 25.1 -
62 49.5 4.1 49.5 49.5 49.5 41.4 33.3 25.2 45.6 4.6 45.6 45.6 45.6 37.5 29.4 21.4
57 47.7 4.0 47.7 47.7 47.7 39.5 31.4 23.3 44.8 4.6 44.8 44.8 44.8 36.7 28.7 20.6
