York AFFINITY BHZ - Page 34

718419-YTG-D-0613
34 Johnson Controls Unitary Products
115°F 125°F
1450
77 49.5 5.2 24.5 19.3 13.6 - - - 39.3 5.8 24.6 15.9 10.4 - - -
72 46.6 5.2 34.2 28.5 22.8 17.1 - - 38.6 5.7 31.3 25.7 20.2 14.7 - -
67 43.8 5.1 43.8 37.7 32.0 26.3 20.6 - 38.0 5.7 38.0 35.5 30.0 24.5 18.9 -
62 39.2 5.1 39.2 39.2 37.0 31.3 25.6 19.9 34.2 5.6 34.2 34.2 34.2 28.5 23.0 17.5
1500
77 50.0 5.2 26.3 19.9 14.0 - - - 40.3 5.8 26.0 16.6 10.8 - - -
72 47.1 5.2 35.2 29.4 23.5 17.6 - - 39.6 5.7 32.4 26.7 20.9 15.1 - -
67 44.2 5.1 44.2 38.8 32.9 27.1 21.2 - 38.9 5.6 38.9 36.8 31.0 25.2 19.4 -
62 39.6 5.1 39.6 39.6 38.1 32.2 26.3 20.4 35.0 5.6 35.0 35.0 35.0 29.4 23.7 17.9
57 39.8 5.1 39.8 39.8 38.3 32.4 26.6 20.7 36.3 5.6 36.3 36.3 35.7 29.9 24.1 18.3
1550
77 50.4 5.2 28.1 20.5 14.4 - - - 41.4 5.8 27.4 17.2 11.2 - - -
72 47.5 5.2 36.3 30.2 24.1 18.0 - - 40.6 5.7 33.6 27.6 21.6 15.6 - -
67 44.5 5.1 44.5 40.0 33.9 27.8 21.7 - 39.8 5.6 39.8 38.0 32.0 26.0 20.0 -
62 39.9 5.1 39.9 39.9 39.2 33.1 27.0 20.9 35.8 5.6 35.8 35.8 35.8 30.3 24.3 18.3
57 40.2 5.1 40.2 40.2 39.4 33.3 27.2 21.1 37.2 5.6 37.2 37.2 36.8 30.8 24.8 18.8
1600
77 50.8 5.2 29.9 21.1 14.8 - - - 42.5 5.7 28.8 17.8 11.5 - - -
72 47.9 5.2 37.4 31.1 24.8 18.5 - - 41.6 5.7 34.8 28.5 22.3 16.0 - -
67 44.9 5.1 44.9 41.1 34.8 28.5 22.2 - 40.7 5.6 40.7 39.2 33.0 26.7 20.5 -
62 40.3 5.1 40.3 40.3 40.3 33.9 27.6 21.3 36.7 5.6 36.7 36.7 36.7 31.2 25.0 18.7
57 40.5 5.1 40.5 40.5 40.5 34.2 27.9 21.6 38.0 5.6 38.0 38.0 38.0 31.7 25.5 19.2
1800
72 48.7 5.2 40.7 33.5 26.3 19.2 - - 42.2 5.7 37.9 30.8 23.6 16.5 - -
67 45.7 5.1 45.7 43.8 37.0 29.8 22.7 - 41.3 5.6 41.3 41.3 35.0 27.9 20.8 -
62 41.0 5.1 41.0 41.0 41.0 33.8 26.6 19.4 37.2 5.6 37.2 37.2 37.2 30.5 23.4 16.2
57 41.2 5.1 41.2 41.2 41.2 34.1 26.9 19.7 38.5 5.6 38.5 38.5 38.5 31.4 24.3 17.2
2000
72 49.6 5.2 44.0 35.9 27.9 19.9 - - 42.8 5.7 41.0 33.0 25.0 17.0 - -
67 46.5 5.1 46.5 46.5 39.2 31.1 23.1 - 41.9 5.6 41.9 41.9 37.1 29.1 21.1 -
62 41.7 5.1 41.7 41.7 41.7 33.6 25.6 17.6 37.7 5.6 37.7 37.7 37.7 29.7 21.7 13.7
57 41.9 5.1 41.9 41.9 41.9 33.9 25.9 17.8 39.1 5.6 39.1 39.1 39.1 31.1 23.1 15.1
1. These capacities are Net Capacities.
2. These ratings include the compressor, condenser fan and supply air blower motors.
BHQ060 (5.0 Ton) (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
