BHX024-060 Cooling Capacities
BHX024 (2.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
1. These capacities are Net Capacities.
Total
Input
(kW)
2
2. These ratings include the compressor, condenser fan and supply air blower motors.
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
600
77 26.8 1.1 14.8 11.4 8.4 - - - 24.6 1.2 15.2 10.8 7.8 - - -
72 24.1 1.1 18.1 15.0 12.0 9.0 - - 22.1 1.2 17.4 14.4 11.3 8.3 - -
67 21.4 1.0 21.4 18.7 15.6 12.6 9.6 - 19.7 1.2 19.7 17.9 14.9 11.8 8.8 -
62 19.6 1.1 19.6 19.6 19.1 16.1 13.0 10.0 18.1 1.2 18.1 18.1 17.8 14.7 11.7 8.6
57 19.4 1.1 19.4 19.4 19.2 16.2 13.1 10.1 17.9 1.2 17.9 17.9 17.7 14.6 11.6 8.5
800
77 34.1 1.8 17.5 15.3 11.6 - - - 32.0 1.9 18.3 14.5 10.8 - - -
72 31.3 1.7 23.0 19.3 15.6 12.0 - - 29.2 1.9 22.3 18.6 14.9 11.2 - -
67 28.5 1.6 28.5 23.3 19.7 16.0 12.3 - 26.4 1.8 26.4 22.7 19.0 15.3 11.6 -
62 25.3 1.6 25.3 25.3 24.8 21.1 17.4 13.8 23.6 1.8 23.6 23.6 23.2 19.5 15.8 12.1
57 25.0 1.6 25.0 25.0 25.1 21.4 17.8 15.0 23.6 1.8 23.6 23.6 23.4 19.7 16.0 12.7
95°F 105°F
600
77 22.4 1.4 15.5 10.2 7.2 - - - 20.7 1.6 17.3 12.0 6.6 - - -
72 20.2 1.4 16.8 13.7 10.6 7.5 - - 18.3 1.6 16.6 13.8 9.9 6.1 - -
67 18.0 1.4 18.0 17.2 14.1 11.0 7.9 - 16.0 1.6 16.0 15.5 13.3 9.5 5.6 -
62 16.7 1.4 16.7 16.7 16.4 13.4 10.3 7.2 15.3 1.6 15.3 15.3 15.2 11.4 7.6 7.2
57 16.5 1.4 16.5 16.5 16.2 13.1 10.0 7.0 15.0 1.6 15.0 15.0 14.7 10.8 7.0 7.0
800
77 29.8 2.1 19.0 13.8 10.0 - - - 27.3 2.4 19.6 13.1 9.1 - - -
72 27.1 2.1 21.7 17.9 14.2 10.4 - - 24.8 2.3 20.9 17.1 13.3 9.5 - -
67 24.4 2.0 24.4 22.1 18.4 14.6 10.8 - 22.3 2.3 22.3 21.1 17.5 13.7 9.9 -
62 22.0 2.0 22.0 22.0 21.7 17.9 14.1 10.4 20.4 2.3 20.4 20.4 20.1 16.3 12.5 8.7
57 22.3 2.0 22.3 22.3 21.7 17.9 14.1 10.4 20.7 2.3 20.7 20.7 20.1 16.3 12.5 8.7
115°F
600
77 19.0 1.8 19.0 13.8 6.1 - - -
72 16.5 1.8 16.5 13.8 9.3 4.7 - -
67 13.9 1.8 13.9 13.9 12.5 7.9 3.4 -
62 13.9 1.8 13.9 13.9 13.9 9.4 4.8 -
57 13.5 1.9 13.5 13.5 13.1 8.6 4.0 -
800
77 24.8 2.6 20.1 12.4 8.3 - - -
72 22.5 2.6 20.1 16.3 12.4 8.6 - -
67 20.1 2.6 20.1 20.1 16.6 12.8 8.9 -
62 18.8 2.5 18.8 18.8 18.6 14.7 10.9 7.0
57 19.1 2.5 19.1 19.1 18.6 14.7 10.9 7.0
