York AFFINITY BHZ - Page 36

718419-YTG-D-0613
36 Johnson Controls Unitary Products
BHX036 (3.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
1. These capacities are Net Capacities.
Total
Input
(kW)
2
2. These ratings include the compressor, condenser fan and supply air blower motors.
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
900
77 36.8 1.5 20.7 16.2 11.9 - - - 34.2 1.7 21.5 15.2 11.0 - - -
72 33.8 1.5 25.7 21.5 17.3 13.1 - - 31.0 1.8 24.7 20.5 16.3 12.1 - -
67 30.8 1.5 30.8 26.8 22.6 18.4 14.2 - 27.9 1.8 27.9 25.8 21.6 17.4 13.2 -
62 28.3 1.5 28.3 28.3 28.3 24.1 19.8 15.6 26.1 1.8 26.1 26.1 26.1 21.9 17.7 13.5
57 28.1 1.5 28.1 28.1 28.2 23.9 19.7 15.5 26.3 1.7 26.3 26.3 26.2 22.0 17.8 13.6
1200
77 49.8 2.7 24.5 20.9 15.9 - - - 46.0 2.9 24.9 19.4 14.5 - - -
72 44.7 2.6 32.0 27.1 22.1 17.2 - - 41.5 2.8 30.9 26.0 21.0 16.0 - -
67 39.5 2.4 39.5 33.3 28.4 23.4 18.5 - 37.0 2.7 37.0 32.5 27.5 22.5 17.6 -
62 36.5 2.3 36.5 36.5 35.8 30.9 25.9 21.0 34.2 2.6 34.2 34.2 33.9 28.9 23.9 18.9
57 36.6 2.3 36.6 36.6 36.5 31.5 26.6 23.9 34.3 2.6 34.3 34.3 34.2 29.2 24.2 20.4
95°F 105°F
900
77 31.5 2.0 22.4 14.2 10.1 - - - 28.3 2.2 23.1 14.7 9.0 - - -
72 28.2 2.0 23.7 19.5 15.3 11.2 - - 25.3 2.3 22.8 18.5 14.3 10.1 - -
67 25.0 2.0 25.0 24.8 20.6 16.4 12.2 - 22.4 2.3 22.4 22.3 19.6 15.3 11.1 -
62 24.0 2.0 24.0 24.0 24.0 19.8 15.7 11.5 21.7 2.2 21.7 21.7 21.8 17.5 13.3 9.0
57 24.5 2.0 24.5 24.5 24.2 20.0 15.8 11.7 22.4 2.2 22.4 22.4 22.0 17.8 13.6 9.3
1200
77 42.1 3.1 25.3 18.0 13.0 - - - 37.9 3.4 25.6 17.1 12.2 - - -
72 38.2 3.0 29.9 24.8 19.8 14.8 - - 34.6 3.4 28.5 23.6 18.7 13.8 - -
67 34.4 3.0 34.4 31.7 26.7 21.7 16.7 - 31.4 3.3 31.4 30.0 25.2 20.3 15.4 -
62 31.9 2.9 31.9 31.9 31.9 26.9 21.9 16.9 29.5 3.2 29.5 29.5 29.5 24.6 19.7 14.8
57 31.9 2.9 31.9 31.9 31.9 26.9 21.9 16.9 29.6 3.2 29.6 29.6 29.6 24.7 19.8 14.9
115°F
900
77 25.0 2.5 23.8 15.2 8.0 - - -
72 22.5 2.5 21.9 17.6 13.3 9.0 - -
67 19.9 2.5 19.9 19.9 18.5 14.2 9.9 -
62 19.5 2.5 19.5 19.5 19.5 15.2 10.9 6.6
57 20.4 2.5 20.4 20.4 19.9 15.6 11.3 7.0
1200
77 33.7 3.8 25.8 16.3 11.4 - - -
72 31.0 3.7 27.1 22.3 17.5 12.7 - -
67 28.4 3.7 28.4 28.4 23.7 18.9 14.1 -
62 27.1 3.6 27.1 27.1 27.1 22.4 17.6 12.8
57 27.3 3.6 27.3 27.3 27.3 22.5 17.7 12.9
