718419-YTG-D-0613
Johnson Controls Unitary Products 37
BHX048 (4.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
1. These capacities are Net Capacities.
Total
Input
(kW)
2
2. These ratings include the compressor, condenser fan and supply air blower motors.
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1050
77 47.4 2.2 25.0 20.4 15.4 - - - 43.6 2.4 24.5 19.1 14.1 - - -
72 42.5 2.2 31.3 26.3 21.3 16.3 - - 39.6 2.5 30.0 25.0 19.9 14.9 - -
67 37.6 2.3 37.6 32.1 27.1 22.1 17.1 - 35.5 2.6 35.5 30.8 25.8 20.8 15.8 -
62 33.3 2.5 33.3 33.3 31.9 26.9 21.9 16.9 31.0 2.8 31.0 31.0 30.1 25.1 20.0 15.0
57 34.0 2.3 34.0 34.0 33.7 28.6 23.6 18.6 32.0 2.6 32.0 32.0 31.7 26.7 21.7 16.6
1600
77 66.1 3.9 29.2 24.8 18.0 - - - 62.6 4.1 31.5 24.3 17.4 - - -
72 60.2 3.7 41.7 34.9 28.0 21.1 - - 56.7 3.9 41.2 34.2 27.2 20.2 - -
67 54.3 3.5 54.3 44.9 38.0 31.1 24.3 - 50.8 3.8 50.8 44.0 37.0 30.0 23.1 -
62 48.4 3.6 48.4 48.4 49.4 42.5 35.6 28.7 46.5 3.9 46.5 46.5 46.5 39.5 32.6 25.6
57 53.5 3.6 53.5 53.5 48.8 41.9 35.0 32.8 50.5 3.9 50.5 50.5 46.0 39.0 32.1 27.4
95°F 105°F
1050
77 39.9 2.7 24.0 17.8 12.7 - - - 36.8 3.1 23.8 16.4 11.6 - - -
72 36.6 2.8 28.7 23.7 18.6 13.6 - - 33.5 3.1 27.0 22.3 17.5 12.8 - -
67 33.4 2.8 33.4 29.6 24.5 19.5 14.5 - 30.1 3.1 30.1 28.1 23.4 18.7 14.0 -
62 28.8 3.1 28.8 28.8 28.2 23.2 18.1 13.1 26.6 3.4 26.6 26.6 26.1 21.3 16.6 11.9
57 30.1 2.8 30.1 30.1 29.7 24.7 19.7 14.6 27.9 3.2 27.9 27.9 27.5 22.8 18.1 13.4
1600
77 59.0 4.2 33.8 23.9 16.8 - - - 53.4 4.6 34.7 22.5 15.2 - - -
72 53.2 4.2 40.6 33.5 26.4 19.3 - - 48.4 4.6 39.1 31.9 24.7 17.6 - -
67 47.4 4.2 47.4 43.1 36.0 29.0 21.9 - 43.5 4.6 43.5 41.3 34.3 27.1 20.0 -
62 44.7 4.2 44.7 44.7 43.7 36.6 29.5 22.4 42.1 4.5 42.1 42.1 40.3 33.2 26.0 18.8
57 47.5 4.2 47.5 47.5 43.2 36.2 29.1 22.0 44.3 4.5 44.3 44.3 40.1 33.0 25.8 18.7
115°F
1050
77 33.8 3.4 23.6 15.0 10.5 - - -
72 30.4 3.4 25.3 20.8 16.4 12.0 - -
67 26.9 3.5 26.9 26.7 22.3 17.9 13.5 -
62 24.4 3.7 24.4 24.4 23.9 19.5 15.1 10.7
57 25.7 3.5 25.7 25.7 25.3 20.9 16.5 12.1
1600
77 47.8 4.9 35.5 21.1 13.6 - - -
72 43.7 4.9 37.5 30.3 23.1 15.8 - -
67 39.5 5.0 39.5 39.5 32.5 25.3 18.1 -
62 39.6 4.9 39.6 39.6 37.0 29.7 22.5 15.3
57 41.2 4.9 41.2 41.2 37.0 29.8 22.6 15.4
