718419-YTG-D-0613
Johnson Controls Unitary Products 49
BHQ Bottom Duct Application
Model
(Tons)
Mode
Thermostat
Input
Speed
Tap
CFM
External Static Pressure (Inch Water Gauge)
0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Watts Watts Watts Watts Watts Watts Watts Watts Watts
BHQ024
(2.0)
Cool High
Y1+O COOL-A 800 99 118 137 157 177 197 217 238 259
Y1+O COOL-B 600 58 74 91 108 126 143 161 179 197
Y1+O COOL-C 700 76 94 112 130 149 167 186 205 224
Y1+O COOL-D 900 127 146 167 188 209 231 254 277 301
Heat
Heat
Pump
Y1 COOL-A 800 99 118 137 157 177 197 217 238 259
Y1 COOL-B 600 58 74 91 108 126 143 161 179 197
Y1 COOL-C 700 76 94 112 130 149 167 186 205 224
Y1 COOL-D 900 127 146 167 188 209 231 254 277 301
Heat
Pump
+
Aux.
Heat
Y1+W1 COOL-A; HEAT-A 800 99 118 137 157 - - - - -
Y1+W1 COOL-A; HEAT-B 720 80 98 117 135 - - - - -
Y1+W1 COOL-A; HEAT-C 880 121 140 160 181 - - - - -
Y1+W1 COOL-A; HEAT-D 900 127 146 167 188 - - - - -
Y1+W1 COOL-B; HEAT-A 800 99 118 137 157 - - - - -
Y1+W1 COOL-B; HEAT-B 720 80 98 117 135 - - - - -
Y1+W1 COOL-B; HEAT-C 880 121 140 160 181 - - - - -
Y1+W1 COOL-B; HEAT-D 900 127 146 167 188 - - - - -
Y1+W1 COOL-C; HEAT-A 800 99 118 137 157 - - - - -
Y1+W1 COOL-C; HEAT-B 720 80 98 117 135 - - - - -
Y1+W1 COOL-C; HEAT-C 880 121 140 160 181 - - - - -
Y1+W1 COOL-C; HEAT-D 900 127 146 167 188 - - - - -
Y1+W1 COOL-D; HEAT-A 800 99 118 137 157 - - - - -
Y1+W1 COOL-D; HEAT-B 720 80 98 117 135 - - - - -
Y1+W1 COOL-D; HEAT-C 880 121 140 160 181 - - - - -
Y1+W1 COOL-D; HEAT-D 900 127 146 167 188 - - - - -
BHQ030
(2.5)
Cool High
Y1+O COOL-A 1050 232 251 271 291 312 333 354 375 396
Y1+O COOL-B 1000 200 219 238 258 278 298 319 340 361
Y1+O COOL-C 1125 255 274 293 313 333 354 375 396 417
Y1+O COOL-D 1200 285 304 323 343 363 383 404 425 446
Heat
Heat
Pump
Y1 COOL-A 1050 232 251 271 291 312 333 354 375 396
Y1 COOL-B 1000 200 219 238 258 278 298 319 340 361
Y1 COOL-C 1100 245 264 283 303 323 343 364 385 406
Y1 COOL-D 1200 285 304 323 343 363 383 404 425 446
Heat
Pump
+
Aux.
Heat
Y1+W1 COOL-A; HEAT-A 1050 232 251 271 291 - - - - -
Y1+W1 COOL-A; HEAT-B 1000 200 219 238 258 - - - - -
Y1+W1 COOL-A; HEAT-C 1150 265 284 303 323 - - - - -
Y1+W1 COOL-A; HEAT-D 1200 285 304 323 343 - - - - -
Y1+W1 COOL-B; HEAT-A 1050 232 251 271 291 - - - - -
Y1+W1 COOL-B; HEAT-B 1000 200 219 238 258 - - - - -
Y1+W1 COOL-B; HEAT-C 1150 265 284 303 323 - - - - -
Y1+W1 COOL-B; HEAT-D 1200 285 304 323 343 - - - - -
Y1+W1 COOL-C; HEAT-A 1050 232 251 271 291 - - - - -
Y1+W1 COOL-C; HEAT-B 1000 200 219 238 258 - - - - -
Y1+W1 COOL-C; HEAT-C 1150 265 284 303 323 - - - - -
Y1+W1 COOL-C; HEAT-D 1200 285 304 323 343 - - - - -
Y1+W1 COOL-D; HEAT-A 1050 232 251 271 291 - - - - -
Y1+W1 COOL-D; HEAT-B 1000 200 219 238 258 - - - - -
Y1+W1 COOL-D; HEAT-C 1150 265 284 303 323 - - - - -
Y1+W1 COOL-D; HEAT-D 1200 285 304 323 343 - - - -
