York AFFINITY BHZ - Page 50

718419-YTG-D-0613
50 Johnson Controls Unitary Products
BHQ036
(3.0)
Cool High
Y1+O COOL-A 1100 206 237 268 300 332 365 399 434 468
Y1+O COOL-B 1200 245 279 314 349 385 421 457 494 531
Y1+O COOL-C 1000 171 199 227 256 285 316 347 380 413
Y1+O COOL-D 1300 286 326 366 405 444 483 522 562 600
Heat
Heat
Pump
Y1 COOL-A 1200 245 279 314 349 385 421 457 494 531
Y1 COOL-B 1100 206 237 268 300 332 365 399 434 468
Y1 COOL-C 1000 171 199 227 256 285 316 347 380 413
Y1 COOL-D 1300 286 326 366 405 444 483 522 562 600
Heat
Pump
+
Aux.
Heat
Y1+W1 COOL-A; HEAT-A 1200 245 279 314 349 - - - - -
Y1+W1 COOL-A; HEAT-B 1080 199 229 259 290 - - - - -
Y1+W1 COOL-A; HEAT-C 1320 295 336 376 417 - - - - -
Y1+W1 COOL-A; HEAT-D 1200 245 279 314 349 - - - - -
Y1+W1 COOL-B; HEAT-A 1200 245 279 314 349 - - - - -
Y1+W1 COOL-B; HEAT-B 1080 199 229 259 290 - - - - -
Y1+W1 COOL-B; HEAT-C 1320 295 336 376 417 - - - - -
Y1+W1 COOL-B; HEAT-D 1200 245 279 314 349 - - - - -
Y1+W1 COOL-C; HEAT-A 1200 245 279 314 349 - - - - -
Y1+W1 COOL-C; HEAT-B 1080 199 229 259 290 - - - - -
Y1+W1 COOL-C; HEAT-C 1320 295 336 376 417 - - - - -
Y1+W1 COOL-C; HEAT-D 1200 245 279 314 349 - - - - -
Y1+W1 COOL-D; HEAT-A 1200 245 279 314 349 - - - - -
Y1+W1 COOL-D; HEAT-B 1080 199 229 259 290 - - - - -
Y1+W1 COOL-D; HEAT-C 1320 295 336 376 417 - - - - -
Y1+W1 COOL-D; HEAT-D 1200 245 279 314 349 - - - -
BHQ042
(3.5)
Cool High
Y1+O COOL-A 1400 350 398 445 491 535 579 624 670 714
Y1+O COOL-B 1300 301 347 392 437 479 522 568 616 662
Y1+O COOL-C 1500 399 449 498 546 591 636 680 725 767
Y1+O COOL-D 1600 448 500 551 600 647 693 736 779 819
Heat
Heat
Pump
Y1 COOL-A 1400 350 398 445 491 535 579 624 670 714
Y1 COOL-B 1350 316 362 405 448 489 529 570 609 646
Y1 COOL-C 1500 399 449 498 546 591 636 680 725 767
Y1 COOL-D 1600 448 500 551 600 647 693 736 779 819
Heat
Pump
+
Aux.
Heat
Y1+W1 COOL-A; HEAT-A 1500 391 439 486 532 576 - - - -
Y1+W1 COOL-A; HEAT-B 1400 350 398 445 491 535 - - - -
Y1+W1 COOL-A; HEAT-C 1550 420 470 519 566 612 - - - -
Y1+W1 COOL-A; HEAT-D 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-B; HEAT-A 1500 391 439 486 532 576 - - - -
Y1+W1 COOL-B; HEAT-B 1400 350 398 445 491 535 - - - -
Y1+W1 COOL-B; HEAT-C 1550 420 470 519 566 612 - - - -
Y1+W1 COOL-B; HEAT-D 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-C; HEAT-A 1500 391 439 486 532 576 - - - -
Y1+W1 COOL-C; HEAT-B 1400 350 398 445 491 535 - - - -
Y1+W1 COOL-C; HEAT-C 1550 420 470 519 566 612 - - - -
Y1+W1 COOL-C; HEAT-D 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-D; HEAT-A 1500 391 439 486 532 576 - - - -
Y1+W1 COOL-D; HEAT-B 1400 350 398 445 491 535 - - - -
Y1+W1 COOL-D; HEAT-C 1550 420 470 519 566 612 - - - -
Y1+W1 COOL-D; HEAT-D 1600 448 500 551 600 647 - - - -
BHQ Bottom Duct Application (Continued)
Model
(Tons)
Mode
Thermostat
Input
Speed
Tap
CFM
External Static Pressure (Inch Water Gauge)
0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Watts Watts Watts Watts Watts Watts Watts Watts Watts
