York AFFINITY BHZ - Page 51

718419-YTG-D-0613
Johnson Controls Unitary Products 51
BHQ048
(4.0)
Cool High
Y1+O COOL-A 1400 338 383 426 468 509 549 589 627 664
Y1+O COOL-B 1500 391 439 486 532 576 618 660 700 739
Y1+O COOL-C 1600 448 500 551 600 647 693 736 779 819
Y1+O COOL-D 1800 508 568 628 688 748 808 868 928 988
Heat
Heat
Pump
Y1 COOL-A 1600 448 500 551 600 647 693 736 779 819
Y1 COOL-B 1500 391 439 486 532 576 618 660 700 739
Y1 COOL-C 1600 448 500 551 600 647 693 736 779 819
Y1 COOL-D 1800 508 568 628 688 748 808 868 928 988
Heat
Pump
+
Aux.
Heat
Y1+W1 COOL-A; HEAT-A 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-A; HEAT-B 1440 359 405 449 493 535 - - - -
Y1+W1 COOL-A; HEAT-C 1760 546 606 663 718 771 - - - -
Y1+W1 COOL-A; HEAT-D 1800 508 568 628 688 748 - - - -
Y1+W1 COOL-B; HEAT-A 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-B; HEAT-B 1440 359 405 449 493 535 - - - -
Y1+W1 COOL-B; HEAT-C 1760 546 606 663 718 771 - - - -
Y1+W1 COOL-B; HEAT-D 1800 508 568 628 688 748 - - - -
Y1+W1 COOL-C; HEAT-A 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-C; HEAT-B 1440 359 405 449 493 535 - - - -
Y1+W1 COOL-C; HEAT-C 1760 546 606 663 718 771 - - - -
Y1+W1 COOL-C; HEAT-D 1800 508 568 628 688 748 - - - -
Y1+W1 COOL-D; HEAT-A 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-D; HEAT-B 1440 359 405 449 493 535 - - - -
Y1+W1 COOL-D; HEAT-C 1760 546 606 663 718 771 - - - -
Y1+W1 COOL-D; HEAT-D 1800 508 568 628 688 748 - - - -
BHQ060
(5.0)
Cool High
Y1+O COOL-A 1500 387 420 453 487 520 554 587 621 654
Y1+O COOL-B 1600 486 520 553 587 620 654 687 721 754
Y1+O COOL-C 1800 667 700 733 766 800 833 867 900 934
Y1+O COOL-D 2000 857 890 923 956 990 1023 1057 1090 1124
Heat
Heat
Pump
Y1 COOL-A 1800 667 700 733 766 800 833 867 900 934
Y1 COOL-B 1600 486 520 553 587 620 654 687 721 754
Y1 COOL-C 1700 577 610 643 677 710 744 777 811 844
Y1 COOL-D 2000 857 890 923 956 990 1023 1057 1090 1124
Heat
Pump
+
Aux.
Heat
Y1+W1 COOL-A; HEAT-A 1900 762 795 828 861 895 - - - -
Y1+W1 COOL-A; HEAT-B 1975 841 874 907 941 974 - - - -
Y1+W1 COOL-A; HEAT-C 2150 986 1019 1052 1086 1119 - - - -
Y1+W1 COOL-A; HEAT-D 2070 916 949 982 1016 1049 - - - -
Y1+W1 COOL-B; HEAT-A 1900 762 795 828 861 895 - - - -
Y1+W1 COOL-B; HEAT-B 1975 841 874 907 941 974 - - - -
Y1+W1 COOL-B; HEAT-C 2150 986 1019 1052 1086 1119 - - - -
Y1+W1 COOL-B; HEAT-D 2070 916 949 982 1016 1049 - - - -
Y1+W1 COOL-C; HEAT-A 1900 762 795 828 861 895 - - - -
Y1+W1 COOL-C; HEAT-B 1975 841 874 907 941 974 - - - -
Y1+W1 COOL-C; HEAT-C 2150 986 1019 1052 1086 1119 - - - -
Y1+W1 COOL-C; HEAT-D 2070 916 949 982 1016 1049 - - - -
Y1+W1 COOL-D; HEAT-A 1900 762 795 828 861 895 - - - -
Y1+W1 COOL-D; HEAT-B 1975 841 874 907 941 974 - - - -
Y1+W1 COOL-D; HEAT-C 2150 986 1019 1052 1086 1119 - - - -
Y1+W1 COOL-D; HEAT-D 2070 916 949 982 1016 1049 - - - -
BHQ Bottom Duct Application (Continued)
Model
(Tons)
Mode
Thermostat
Input
Speed
Tap
CFM
External Static Pressure (Inch Water Gauge)
0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Watts Watts Watts Watts Watts Watts Watts Watts Watts
