York AFFINITY BHZ - Page 55

718419-YTG-D-0613
Johnson Controls Unitary Products 55
BHX048
(4.0)
Cool
Low
Y1 COOL-A 1050 184 216 248 280 313 346 380 414 448
Y1 COOL-B 918 138 166 194 224 254 286 318 351 385
Y1 COOL-C 984 160 190 220 251 282 315 348 381 416
Y1 COOL-D 1115 210 243 277 311 345 379 414 449 484
High
Y1+Y2 COOL-A 1600 448 500 551 600 647 693 736 779 819
Y1+Y2 COOL-B 1400 338 383 426 468 509 549 589 627 664
Y1+Y2 COOL-C 1500 391 439 486 532 576 618 660 700 739
Y1+Y2 COOL-D 1700 508 565 620 672 723 772 818 863 905
Heat
Heat
Pump
Y1 COOL-A 1600 448 500 551 600 647 693 736 779 819
Y1 COOL-B 1400 338 383 426 468 509 549 589 627 664
Y1 COOL-C 1500 391 439 486 532 576 618 660 700 739
Y1 COOL-D 1700 508 565 620 672 723 772 818 863 905
Heat
Pump
+
Aux.
Heat
Y1+W1 COOL-A; HEAT-A 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-A; HEAT-B 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-A; HEAT-C 1760 546 606 663 718 771 - - - -
Y1+W1 COOL-A; HEAT-D 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-B; HEAT-A 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-B; HEAT-B 1440 359 405 449 493 535 - - - -
Y1+W1 COOL-B; HEAT-C 1760 546 606 663 718 771 - - - -
Y1+W1 COOL-B; HEAT-D 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-C; HEAT-A 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-C; HEAT-B 1500 391 439 486 532 576 - - - -
Y1+W1 COOL-C; HEAT-C 1760 546 606 663 718 771 - - - -
Y1+W1 COOL-C; HEAT-D 1600 448 500 551 600 647 - - - -
Y1+W1 COOL-D; HEAT-A 1700 508 565 620 672 723 - - - -
Y1+W1 COOL-D; HEAT-B 1700 508 565 620 672 723 - - - -
Y1+W1 COOL-D; HEAT-C 1760 546 606 663 718 771 - - - -
Y1+W1 COOL-D; HEAT-D 1700 508 565 620 672 723 - - - -
BHX060
(5.0)
Cool
Low
Y1 COOL-A 1200 138 176 211 244 275 303 329 352 374
Y1 COOL-B 1130 61 98 133 163 190 213 232 247 260
Y1 COOL-C 1270 208 246 283 318 353 386 418 448 478
Y1 COOL-D 1340 272 310 348 386 423 460 497 533 570
High
Y1+Y2 COOL-A 1700 487 531 575 621 668 716 765 816 867
Y1+Y2 COOL-B 1600 446 487 530 574 619 666 714 763 814
Y1+Y2 COOL-C 1800 514 560 607 654 701 749 798 847 897
Y1+Y2 COOL-D 1900 526 576 624 672 720 766 813 859
Heat
Heat
Pump
Y1 COOL-A 1700 487 531 575 621 668 716 765 816 867
Y1 COOL-B 1600 446 487 530 574 619 666 714 763 814
Y1 COOL-C 1800 514 560 607 654 701 749 798 847 897
Y1 COOL-D 1900 526 576 624 672 720 766 813 859 -
Heat
Pump
+
Aux.
Heat
Y1+W1 COOL-A; HEAT-A 1900 526 576 624 672 720 - - - -
Y1+W1 COOL-A; HEAT-B 1975 526 578 628 677 723 - - - -
Y1+W1 COOL-A; HEAT-C 2150 495 554 607 656 699 - - - -
Y1+W1 COOL-A; HEAT-D 2070 515 570 622 671 716 - - - -
Y1+W1 COOL-B; HEAT-A 1900 526 576 624 672 720 - - - -
Y1+W1 COOL-B; HEAT-B 1975 526 578 628 677 723 - - - -
Y1+W1 COOL-B; HEAT-C 2150 495 554 607 656 699 - - - -
Y1+W1 COOL-B; HEAT-D 2070 515 570 622 671 716 - - - -
Y1+W1 COOL-C; HEAT-A 1900 526 576 624 672 720 - - - -
Y1+W1 COOL-C; HEAT-B 1975 526 578 628 677 723 - - - -
Y1+W1 COOL-C; HEAT-C 2150 495 554 607 656 699 - - - -
Y1+W1 COOL-C; HEAT-D 2070 515 570 622 671 716 - - - -
Y1+W1 COOL-D; HEAT-A 1900 526 576 624 672 720 - - - -
Y1+W1 COOL-D; HEAT-B 1975 526 578 628 677 723 - - - -
Y1+W1 COOL-D; HEAT-C 2150 495 554 607 656 699 - - - -
Y1+W1 COOL-D; HEAT-D 2070 515 570 622 671 716 - - - -
BHX Bottom Duct Application (Continued)
Model
(Tons)
Mode
Thermostat
Input
Speed
Tap
CFM
External Static Pressure (Inch Water Gauge)
0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Watts Watts Watts Watts Watts Watts Watts Watts Watts
