York AFFINITY BHZ - Page 64

718419-YTG-D-0613
64 Johnson Controls Unitary Products
BHX 024 - 060 Heat Pump With/Without Electric Heat
Models
(Tons)
Volt
Compressors
OD Fan
Motors
Supply
Blower
Motor
Electric Heat Option
MCA
1
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA Model kW Stages Amps
BHX024
(2.0)
208/230-1-60 10.2 52 16 0.9 4.3
None - - - 18 25
2NH04500506 3.8/5 1 18.1/20.8 40.5/44 45/45
2NH04500706 5.6/7.5 2 27.1/31.3 51.8/57 60/60
2NH04501006 7.5/10 2 36.1/41.7 63.1/70 70/80
2NE04500706 5.6 / 7.5 2 27.1 / 31.3 33.9 / 39.1 35 / 40
2NE04501006 7.5 / 10 2 36.1 / 41.7 45.1 / 52.1 50 / 60
BHX036
(3.0)
208/230-1-60 16.6 82 26 1.1 6.8
None - - - 28.7 35
2NH04500506 3.8/5 1 18.1/20.8 51.2/54.7 60/60
2NH04500706 5.6/7.5 2 27.1/31.3 62.5/67.7 70/70
2NH04501006 7.5/10 2 36.1/41.7 73.8/80.7 80/90
2NH04501506 11.3/15 2 54.2/62.5 96.4/106.8 100/110
2NE04500706 5.6 / 7.5 2 27.1 / 31.3 33.9 / 39.1 35 / 40
2NE04501006 7.5 / 10 2 36.1 / 41.7 45.1 / 52.1 50 / 60
2NE04501506 11.3 / 15 2 54.2 / 62.5 67.7 / 78.1 70 / 80
208/230-3-60 11.1 58 17 1.1 6.8
None - - - 21.8 30
2NH04501025 7.5/10 1 20.8/24.1 47.8/51.8 50/60
2NH04501525 11.3/15 1 31.3/36.1 60.9/66.9 70/70
460-3-60 4.5 29 7 0.6 3.4
None - - - 9.6 15
2NH04501046 10 1 12 24.7 25
2NH04501546 15 1 18 32.2 35
BHX048
(4.0)
208/230-1-60 21.1 96 33 2.6 6.8
None - - - 35.8 45
2NP04501006 7.5/10 2 36.1/41.7 80.9/87.9 90/90
2NP04501506 11.3/15 2 54.2/62.5 103.5/113.9 110/125
2NP04502006 15/20 2 72.2/83.3 126.1/139.9 150/150
2NP04502506 18.8/25 2 90.3/104.2 148.6/166 150/175
2NE04501006 7.5 / 10 2 36.1 / 41.7 45.1 / 52.1 50 / 60
2NE04501506 11.3 / 15 2 54.2 / 62.5 67.7 / 78.1 70 / 80
2NE04502006 15 / 20 2 72.2 / 83.3 90.3 / 104.2 100 / 110
2NE04502506 18.8 / 25 2 90.3 / 104.2 112.8 / 130.2 125 / 150
208/230-3-60 13.4 88 21 2.6 6.8
None - - - 26.2 35
2NP04501025 7.5/10 1 20.8/24.1 52.2/56.2 60/60
2NP04501525 11.3/15 1 31.3/36.1 65.2/71.3 70/80
2NP04502025 15/20 2 41.7/48.1 78.3/86.3 80/90
2NP04502525 18.8/25 2 52.1/60.1 91.3/101.3 100/110
460-3-60 6.4 41 10 1.3 3.4
None - - - 12.7 15
2NP04501046 10 1 12 27.7 30
2NP04501546 15 1 18 35.3 40
2NP04502046 20 2 24.1 42.8 45
2NP04502546 25 2 30.1 50.3 60
BHX060
(5.0)
208/230-1-60 25.6 118 40 2.5 9.1
None - - - 43.6 60
2NP04501006 7.5/10 2 36.1/41.7 88.7/95.7 100/110
2NP04501506 11.3/15 2 54.2/62.5 111.3/121.7 125/125
2NH04502006 15/20 2 72.2/83.3 133.9/147.8 150/150
2NP04502506 18.8/25 2 90.3/104.2 156.4/173.8 175/175
2NE04501006 7.5 / 10 2 36.1 / 41.7 45.1 / 52.1 50 / 60
2NE04501506 11.3 / 15 2 54.2 / 62.5 67.7 / 78.1 70 / 80
2NE04502006 15 / 20 2 72.2 / 83.3 90.3 / 104.2 100 / 110
2NE04502506 18.8 / 25 2 90.3 / 104.2 112.8 / 130.2 125 / 150
208/230-3-60 17.6 135 28 2.5 9.1
None - - - 33.6 45
2NH04501025 7.5/10 1 20.8/24.1 59.7/63.7 70/70
2NH04501525 11.3/15 1 31.3/36.1 72.7/78.7 80/80
2NH04502025 15/20 2 41.7/48.1 85.7/93.7 90/100
2NH04502525 18.8/25 2 52.1/60.1 98.8/108.8 100/110
460-3-60 9.0 62 14 1.3 4.6
None - - - 17.2 25
2NP04501046 10 1 12 32.2 35
2NH04501546 15 1 18 39.7 40
2NH04502046 20 2 24.1 47.2 50
2NP04502546 25 2 30.1 54.7 60
1. Minimum Circuit Ampacity.
2. Maximum Over Current Protection per standard UL 1995.
3. Fuse or HACR circuit breaker size installed at factory or field installed.
