York AFFINITY BHZ - Page 63

718419-YTG-D-0613
Johnson Controls Unitary Products 63
BHQ060
(5.0)
208/230-1-60 25.0 134 39 4.4 9.1
None - - - 44.8 60
2NP04501006 7.5 / 10 2 36.1 / 41.7 89.9 / 96.8 100 / 110
2NP04501506 11.3 / 15 2 54.2 / 62.5 112.5 / 122.9 125 / 125
2NH04502006 15 / 20 2 72.2 / 83.3 135 / 148.9 150 / 150
2NP04502506 18.8 / 25 2 90.3 / 104.2 157.6 / 175 175 / 175
2NE04501006 7.5 / 10 2 36.1 / 41.7 45.1 / 52.1 50 / 60
2NE04501506 11.3 / 15 2 54.2 / 62.5 67.7 / 78.1 70 / 80
2NE04502006 15 / 20 2 72.2 / 83.3 90.3 / 104.2 100 / 110
2NE04502506 18.8 / 25 2 90.3 / 104.2 112.8 / 130.2 125 / 150
208/230-3-60 15.9 110 25 4.4 9.1
None - - - 33.4 45
2NH04501025 7.5 / 10 1 20.8 / 24.1 59.4 / 63.4 70 / 70
2NH04501525 11.3 / 15 1 31.3 / 36.1 72.5 / 78.5 80 / 80
2NH04502025 15 / 20 2 41.7 / 48.1 85.5 / 93.5 90 / 100
2NH04502525 18.8 / 25 2 52.1 / 60.1 98.5 / 108.6 100 / 110
460-3-60 7.0 52 11 2.2 4.6
None - - - 15.6 20
2NP04501046 10 1 12 30.6 35
2NH04501546 15 1 18 38.1 40
2NH04502046 20 2 24.1 45.6 50
2NP04502546 25 2 30.1 53.1 60
1. Minimum Circuit Ampacity.
2. Maximum Over Current Protection per standard UL 1995.
3. Fuse or HACR circuit breaker size installed at factory or field installed.
BHQ 024 - 060 Heat Pump With/Without Electric Heat (Continued)
Model
(Tons)
Volt
Compressors
OD Fan
Motors
Supply
Blower
Motor
Electric Heat Option
MCA
1
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA Model kW Stages Amps
