York AFFINITY BHZ - Page 8

718419-YTG-D-0613
8 Johnson Controls Unitary Products
BHQ Physical Data
Component
Models
BHQ024 BHQ030 BHQ036 BHQ042 BHQ048 BHQ060
Nominal Tonnage 2.0 2.5 3.0 3.5 4.0 5.0
AHRI COOLING PERFORMANCE
Gross Capacity @ AHRI A point (MBH) 23.3 29.4 35.9 40.1 47.4 54.5*
AHRI net capacity (MBH) 23 28.6 35.2 39.0 46.5 54.0*
EER 12.0 12.0 12.0 12.0 12.0 12.0*
SEER 14.0 14.0 14.0 14 14.0 14.0*
Nominal CFM 800 1050 1100 1400 1400 1500
System power (KW) 1.9 2.4 2.9 3.3 3.9 4.5
Refrigerant type R410A R410A R410A R410A R410A R410A
Refrigerant charge (lb-oz) 7-12 9-12 9-10 12-12 11-12 13-12
AHRI HEATING PERFORMANCE
47°F Capacity Rating (MBH) 20 27.3 33.0 37.5 46.0 53.0
System Power (Kw/COP) 3.3 3.3 3.3 3.3/3.3 3.3 3.3
17°F Capacity Rating (MBH) 11.1 15.5 18.2 19.5 21.8 29.8
System Power (Kw/COP) 2.1 2.2 2.2 2.4/2.32 2.1 2.2
HSPF (BTU/Watts-hr.) 8.0 8.0 8.0 8.0 8.0 8.0
DIMENSIONS (inches)
Length 49 1/8 49 1/8 49 1/8 49 1/8 49 1/8 49 1/8
Width 47 1/4 47 1/4 47 1/4 47 1/4 47 1/4 47 1/4
Height 33 1/2 33 1/2 33 1/2 41 1/2 41 1/2 41 1/2
OPERATING WT. (lbs.)
Unit Weight (lbs.) 355 375 400 420 440 490
COMPRESSOR
Type Scroll 1-spd Scroll 1-spd Scroll 1-spd Scroll 1-spd Scroll 1-spd Scroll 1-spd
CONDENSER COIL DATA
Face area (Sq. Ft.) 12.9 12.9 12.9 16.4 16.4 16.4
Rows 122223
Fins per inch 20 20 20 20 20 13
Tube diameter (in.) 3/8 3/8 3/8 3/8 3/8 3/8
Refrigerant control TXV TXV TXV TXV TXV TXV
EVAPORATOR COIL DATA
Face area (Sq. Ft.) 4.38 4.38 4.38 5.63 5.63 5.63
Rows 333333
Fins per inch 15 15 15 16 16 13
Tube diameter 3/8 3/8 3/8 3/8 3/8 3/8
Refrigerant control TXV TXV TXV TXV TXV TXV
CONDENSER FAN DATA
Fan diameter (Inch) 22 22 22 22 22 22
Type Prop Prop Prop Prop Prop Prop
Drive type Direct Direct Direct Direct Direct Direct
Motor HP 1/3 1/3 1/3 1/3 1/3 1/2
No. speeds 1 1 1 1 1 1
RPM 1100 1100 1100 1100 1100 1100
Nominal total CFM 2000 2400 2400 3200 3200 3400
DIRECT DRIVE EVAP FAN DATA
Fan Size (Inch) 10 x 8 10 x 8 11 x 10 11 x 10 11 x 10 11 x 10
Type Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
No. speeds 1 1 1 1 1 1
Motor HP 1/2 1/2 3/4 3/4 3/4 1
RPM Variable Variable Variable Variable Variable Variable
Frame size 48 48 48 48 48 48
FILTERS
Quantity - Size 2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1
