718419-YTG-D-0613
Johnson Controls Unitary Products 9
BHX Physical Data
Component
Models
BHX024 BHX036 BHX048 BHX060
Nominal Tonnage 2.0 3.0 4.0 5.0
AHRI COOLING PERFORMANCE
Gross Capacity @ AHRI A point (MBH) 24.9 35.3 49.2 58.8
AHRI net capacity (MBH) 24.4 34.4 47.0 57.0
EER 12.0 11.5 11.3 11.0
SEER 16 15 15 14.25
Nominal CFM 800 1200 1600 1700
System power (KW) 2.0 3.0 4.2 5.2
Refrigerant type R410A R410A R410A R410A
Refrigerant charge (lb-oz) 7-10 10-4 12-4 12-0
AHRI HEATING PERFORMANCE
47°F Capacity Rating (MBH) 19.8 33.0 45.0 55.0
System Power (Kw/COP) 3.5 3.1 3.0 3.1
17°F Capacity Rating (MBH) 11.1 18.9 27.2 32.4
System Power (Kw/COP) 2.1 2.0 2.1 2.1
HSPF (BTU/Watts-hr.) 8.0 8.0 8.0 8.0
DIMENSIONS (inches)
Length 49 1/8 49 1/8 49 1/8 49 1/8
Width 47 1/4 47 1/4 47 1/4 47 1/4
Height 33 1/2 33 1/2 41 1/2 41 1/2
OPERATING WT. (lbs.)
Unit Weight (lbs.) 350 400 440 460
COMPRESSOR
Type Scroll 2-spd Scroll 2-spd Scroll 2-spd Scroll 2-spd
CONDENSER COIL DATA
Face area (Sq. Ft.) 11.7 11.7 16.4 16.4
Rows 1222
Fins per inch 20 20 20 20
Tube diameter (in.) 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced
Refrigerant control Orifice TXV TXV TXV
EVAPORATOR COIL DATA
Face area (Sq. Ft.) 4.38 4.38 5.63 5.63
Rows 3333
Fins per inch 15 15 16 16
Tube diameter 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced
Refrigerant control TXV TXV TXV TXV
CONDENSER FAN DATA
Fan diameter (Inch) 22 22 22 22
Type Axial Axial Axial Axial
Drive type Direct Direct Direct Direct
No. speeds 2 1 2 2
Motor HP 1/3 1/4 1/3 1/3
RPM 850/1100 1100 900/1100 950/1100
Nominal total CFM 2400 2400 3000 3000
DIRECT DRIVE EVAP FAN DATA
Fan Size (Inch) 10 x 8 11 x 10 11 x 10 11 x 10
Type Centrifugal Centrifugal Centrifugal Centrifugal
No. speeds 1 1 1 1
Motor HP 1/2 3/4 3/4 1
RPM Variable Variable Variable Variable
Frame size 48 48 48 48
FILTERS
Quantity - Size 2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1 2 - 22 x 14 x 1
