036-33072-001 Rev. A (0601)
Unitary Products Group 15
TABLE 1: SUPPLY AIR BLOWER PERFORMANCE
MODEL
#
SUPPLY
CFM
EXTERNAL STATIC PRESSURE - Inches W. C.
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 2.2 2.4 2.6 2.8 3.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
CU060A
1800 791 0.46 872 0.53 948 0.60 1019 0.68 1090 0.76 1159 0.85
1193 0.89 1259 0.98 1321 1.07 1380 1.16 1437 1.25 1492 1.35 1544 1.44 - - - -
2000 860 0.60 935 0.69 1006 0.77 1077 0.85 1136 0.94 1199 1.03 1263 1.12 1324 1.22 1383 1.32 1440 1.42 1494 1.52 - - - - - - - -
2200 931 0.7910010.8810670.971129 1.06 1189 1.15 1247 1.25 1305 1.35 1363 1.45 1419 1.55 - - - - - - - - - - - -
CU096A
3000 568 0.70 628 0.81 688 0.92 746 1.05 801 1.19 855 1.35 906 1.50 954 1.65 1001 1.81 1046 1.97 - - - - - - - - - -
3200 594 0.82 651 0.94 707 1.06 762 1.19 816 1.33 867 1.49 917 1.65 964 1.81 1010 1.98 - - - - - - - - - - - -
3400 625 0.97 679 1.10 731 1.22 784 1.35 835 1.50 884 1.66 933 1.83 979 2.00 - - - - - - - - - - - - - -
CU120A
3600 620 1.04 666 1.16 716 1.29 765 1.43 815 1.56 864 1.71 912 1.88 958 2.00 1003 2.03 1046 2.41 1088 2.60 1129 2.78 1169 2.97 - - - -
4000 681 1.40 721 1.53 765 1.68 811 1.83 856 1.97 900 2.13 9.45 2.29 988 2.46 1030 2.65 1071 2.84 1112 3.05 - - - - - - - -
4400 726 1.77 760 1.91 797 2.05 837 2.21 878 2.38 919 2.54 960 2.70 1001 2.87 1040 3.05 - - - - - - - - - - - -
CU180A
5400 645 1.52 709 1.79 770 2.06 829 2.35 885 2.65 939 2.96 991 3.28 1042 3.61 1092 3.96 1140 4.32 1190 4.71 - - - - - - - -
6000 700 2.00 759 2.30 815 2.60 870 2.91 922 3.23 973 3.56 1022 3.90 1070 4.25 1116 4.62 1162 4.99 - - - - - - - - - -
6600 761 2.63 815 2.94 867 3.26 917 3.60 966 3.94 1014 4.29 1060 4.66 1104 5.02 - - - - - - - - - - - - - -
CU240A
7200 659 2.10 714 2.37 767 2.65 817 2.94 866 3.23 912 3.52 957 3.82 998 4.13 1037 4.44 1076 4.76 1115 5.11 1154 5.47 1193 5.73 1230 6.10 1265 6.46
8000 719 2.81 770 3.11 818 3.42 865 3.73 910 4.05 954 4.37 997 4.70 1038 5.03 1078 5.36 1115 5.71 1151 6.08 1186 6.46 1220 6.84 1254 7.23 - -
8800 782 3.67 828 4.00 873 4.34 916 4.68 959 5.02 1000 5.37 1040 5.73 1079 6.09 1117 6.45 1154 6.81 1190 7.18 - - - - - - - -
CU300A
9000 800 3.93 846 4.27 890 4.61 932 4.96 974 5.32 1014 5.67 1053 6.03 1092 6.40 1129 6.77 1166 7.14 1202 7.51 1237 7.90 1271 8.28 1304 8.66 - -
10000 878 5.29 920 5.67 960 6.05 999 6.43 1037 6.82 1074 7.21 1111 7.61 1147 8.01 1182 8.41 1216 8.82 1250 9.22 1238 9.63 1315 10.04 - - - -
11000 958 6.95 996 7.37 1033 7.79 1069 8.21 1104 8.63 1139 9.05 1173 9.48 1206 9.92 - - - - - - - - - - - - - -
NOTE:
At higher evaporator airflows and wet bulb conditions, condensate carry-over may occur. Adjust airflow downward as necessary.
Values include pressure drop from wet coil and clean filters.
Shaded areas indicate oversize motor and/or drive set required.
