036-33072-001 Rev. A (0601)
Unitary Products Group 5
Location -To ensure unit operates at maximum efficiencies,
choose a dry indoor area where the temperature is controlled
between 50 deg F and 115deg F. Consideration of surround-
ing areas should be taken when choosing a location to install
the unit. Common vibration and sound levels associated with
commercial equipment may be objectionable to people or
equipment. Install thermostats, air supplies and returns so
that each unit will operate only on individual unit control.
UNIT MOUNTING
The 5 through 25 ton models are shipped as a fully assem-
bled integral package. The 5-15 ton units may be field split
between the evaporator/compressor section and the upper
blower section; to allow for passage through doors, elevators,
hallways, etc. Units are not intended for outdoor installation.
Floor mounted units should be secured on a solid, level sur-
face or sturdy stand. (refer to typical installation diagram on
Page 4). The use of an isolating rubber sheet is recom-
mended to reduce vibration and noise transmission. Ensure
that the entire base is continuosly supported -do not support
unit at corner points only!
GENERAL DATA
TABLE 1: GENERAL UNIT INFORMATION
Note: The water cooled coaxial condensers in these units
have copper tubing and are NOT suitable for salt or brackish
water. Do not install these units outdoors, or in any area
where the surrounding temperature may drop below 32
degrees F.
LOCK ALL ELECTRICAL POWER SUPPLY
SWITCHES IN THE OFF POSITION BEFORE
INSTALLING THE UNIT. FAILURE TO DISCON-
NECT POWER SUPPLY MAY RESULT IN ELEC-
TRICAL SHOCK OR EVEN DEATH.
WARNING
Model CU060 CU096 CU120 CU180 CU240 CU300
Nominal Cooling (Ton) 5 8 10 15 20 25
Cooling Performance
Gross Cooling Capacity (Btuh) 63300 100600 127800 188600 246800 322000
Design CFM 2000 3200 4000 6000 8000 10000
Compressor - Type Scroll
NumberUsed 1 2222 2
Evaporator Coil - Type Copper Tubes, Aluminum Fins
Face Area (sq. ft.) 5.00 9.37 10.50 15.11 19.00 19.79
Rows/FPI 3/12 3/12 3/13 3/12 3/14 4/12
Condenser - Type Coaxial
Number Used/Tons Capacity 1/5 2/4 2/5 2/7.5 2/10 3/7.5
Nominal Water flow rate (gpm) 15 24 30 45 60 75
Unit Water Connection Size 1” FPT 1-1/4” FPT 1-1/4” FPT 1-1/2” FPT 2” FPT 2” FPT
Evaporator Fan - Type Centrifugal, Forward Curved
NumberUsed 1 1122 2
Diameter x Width (in.) 12x9 15x12 15x12 15x9 15x11 15x11
Drive Adjustable Belt
Motor HP (Standard/Oversize) 0.75/1 1.5/2 2/3 3/5 5/7.5 7.5/10
Filters
Number Used-Size (in.) 2-20x16 4-14x25x2 6-14x20x2 2-16x20x2
4-16x25x2
6-20x25x2 8-20x20x2
Condensate Drain Connection 3/4 FPT
Weight
Shipping 625 815 975 1350 1525 1825
NOTE: Cooling performance is rated at 80 degrees F dry bulb 67 degrees F wet bulb entering air temperature, CFM listed,
85 degrees F entering 95 degrees F leaving water temperature, and water flow rate listed.
Gross capacity does not include the effect of evaporator fan motor heat.
