York DC-090 - Dry Coil Delta P 42 Cabinet

5120410-XIM-B-0216
44 Johnson Controls Unitary Products
Figure 28: Dry Coil Delta P 42” Cabinet
PREDATOR
®
42" CABINET, 50 HZ UNITS
INDOOR COIL PRESSURE DROP VS AIRFLOW
0.2
0.25
0.3
0.35
0.4
0.5
0.55
0.45
2000 2500 3000 3500 4000 4500
Airflow (CFM)
Dry Coil Delta P (IWG)
DC 090
