Page 28
Aux Output Polarity (Setup Step 57)
Open (Normally Open) or Closed (Normally Closed).
- Specifies if the Auxiliary output will be
Aux Output (Setup Step 58)
Choices are:
- Specifies which source will control the Aux output.
Aux Output Days (Setup Step 59) - Specifies if the Aux Output will be single day (1
DAY), weekday/weekend (5/2 DAY), or seven day (7 DAY) programmable.
Day Of Week To Program (Setup Step 60) - Specifies which day of week to program.
Auxiliary Output Programming By Time
Aux Output Start Time (Setup Step 61) - Specifies the time of each day when the
Aux output will turn on.
Aux Output Stop Time (Setup Step 62) - Specifies the time of each day when the
Aux output will turn off.
Copy (Setup Step 63) - This step only appears if Aux Output Days (Setup Step 59) is
set for 7 programmable output days.
If TIME is selected for the Aux Output, the following setup steps will appear:
Auxiliary Output
The LX Thermostat is equipped with a programmable auxiliary output. This output can
be configured to be controlled from a variety of sources.
Time - Uses the internal clock of the thermostat.
Temp - Uses one of three temperature sources.
Error - Uses the thermostat’s error processing to signal an active error condition.
Free Cooling - Drives a damper to bring fresh air in from outdoors.
Venting - Drives a damper to exhaust inside air to the outside.
(This feature not available on all models)
Installer Setup
External - The Auxiliary Output is controlled from an external accessory source,
like Comfort Call.
