York MAXE OPTIVIEW YK - Fig. 62 - Drop Leg Refrigerant Sensor; Fig. 63 - Evaporator Refrigerant Sensor

FORM 160.54-M1(503)
119
YORK INTERNATIONAL
FIG. 62 – DROP LEG REFRIGERANT SENSOR FIG. 63 – EVAPORATOR REFRIGERANT SEN SOR
Temp (°F) Temp (°C) Vin
0.01 -17.77 0.753
3.72 -15.71 0.831
7.21 -13.77 0.909
10.51 -11.94 0.987
13.65 -10.20 1.066
16.65 -8.53 1.144
19.56 -6.91 1.222
22.36 -5.36 1.300
25.09 -3.84 1.378
27.74 -2.37 1.456
30.34 -0.92 1.534
32.89 0.49 1.613
35.40 1.89 1.691
37.87 3.26 1.769
40.31 4.62 1.847
42.73 5.96 1.925
45.14 7.30 2.003
47.53 8.63 2.081
49.92 9.96 2.160
52.31 11.28 2.238
54.70 12.61 2.316
57.10 13.95 2.394
59.52 15.29 2.472
61.95 16.64 2.550
64.40 18.00 2.628
66.89 19.38 2.707
69.40 20.78 2.785
71.97 22.21 2.863
74.57 23.65 2.941
77.23 25.13 3.019
79.96 26.65 3.097
82.73 28.19 3.175
85.60 29.78 3.254
88.56 31.42 3.332
91.59 33.11 3.410
94.75 34.86 3.488
98.06 36.70 3.566
101.50 38.61 3.644
105.10 40.61 3.722
108.90 42.73 3.801
112.92 44.96 3.879
117.17 47.32 3.957
121.76 49.87 4.035
Temp (°F) Temp (°C) Vin
0.04 -17.76 1.135
2.79 -16.23 1.214
5.44 -14.76 1.292
8.02 -13.32 1.370
10.53 -11.93 1.448
12.98 -10.57 1.526
15.39 -9.23 1.604
17.75 -7.92 1.683
20.08 -6.62 1.761
22.38 -5.34 1.839
24.66 -4.08 1.917
26.92 -2.82 1.995
29.17 -1.57 2.073
31.41 -0.33 2.151
33.66 0.92 2.230
35.90 2.17 2.308
38.15 3.42 2.386
40.41 4.67 2.464
42.69 5.94 2.542
44.99 7.72 2.620
47.31 8.51 2.698
49.67 9.82 2.777
52.06 11.15 2.855
54.49 12.50 2.933
56.96 13.87 3.011
59.50 15.28 3.089
62.10 16.72 3.167
64.77 18.21 3.245
67.51 19.73 3.324
70.35 21.31 3.402
73.29 22.94 3.480
76.36 24.65 3.558
79.55 26.42 3.636
82.89 28.27 3.714
86.41 30.23 3.792
90.12 32.29 3.871
94.07 34.49 3.949
98.31 36.84 4.027
102.87 39.38 4.105
107.81 42.12 4.183
113.26 45.15 4.261
119.30 48.50 4.339
126.10 52.28 4.418
Temperature Thermistors
18
