BLOWER PERFORMANCE - DOWNFLOW - CFM (Includes Filter)
MODEL
SPEED
TAP
EXTERNAL STATIC PRESSURE, INCHES W.C.
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00
P2DPD10
*
04801
HIGH 1356 1315 1222 1154 1090 988 888 771 630 462
MED 1144 1080 1023 958 919 830 740 635 510 425
LOW 967 942 908 864 811 747 672 574 476 344
P2DPD12
*
06401
HIGH 1557 1502 1410 1344 1240 1142 1025 882 740 567
MED 1289 1238 1175 1098 1030 938 855 712 582 455
LOW 1136 1081 1039 965 906 831 739 617 515 413
P2DPD12
*
08001
HIGH 1599 1535 1465 1375 1277 1182 1089 948 723 554
MED 1390 1327 1266 1195 1109 1027 919 813 597 458
LOW 1175 1136 1093 1027 967 900 816 764 497 382
P2DPD16
*
08001
HIGH 2043 2000 1893 1823 1726 1627 1503 1382 1249 1134
MED 1706 1655 1593 1533 1450 1366 1265 1163 1062 950
LOW 1452 1406 1373 1317 1245 1174 1112 1025 935 817
P2DPD16
*
09201
HIGH 2053 1977 1899 1817 1725 1623 1519 1401 1265 1120
MED 1711 1667 1606 1530 1458 1383 1284 1184 1066 951
LOW 1460 1434 1407 1363 1310 1232 1137 1064 964 854
P2DPD20
*
10401
HIGH 2330 2248 2177 2103 2024 1910 1789 1698 1555 1419
MED 1867 1858 1814 1740 1675 1593 1524 1443 1330 1204
LOW 1613 1531 1516 1490 1495 1411 1337 1250 1225 1010
Operation at these heating conditions exceed the listed temperature rise range. A higher blower
speed must be selected.
* Model designator may be "N" for standard units, or "L" for factory built low NOx units.
Airlfow is expressed in standard cubic feet per minute.
Motor voltage at 115V
