York R-407C Optimized - Page 100

100
YORK INTERNATIONAL
101
YORK INTERNATIONAL
FORM 201.19-EG4
OPTIONAL SINGLE-POINT POWER SUPPLY CONNECTION WITH INDIVIDUAL SYSTEM CIRCUIT
BREAKERS – 3 & 4 COMPRESSOR UNITS (SEE FIG. 7)
(One Field Provided Power Supply Circuit to the chiller. Field connections to Factory Provided Terminal Block (standard) or Non-Fused Disconnect (option)
in Options Panel. Individual System Circuit Breakers in each Motor Control Center)
Electrical Data (continued)
SYSTEM #1 FIELD-SUPPLIED WIRING
FACTORY PROVIDED (LUGS)
MODEL
VOLTS MIN NF
WIRE RANGE
7
COMPRESSOR #3 FANS
11, 12
YCAS MCA
1
DISC SW
2, 9
STD. TERMINAL OPT. NF.
RLA Y-D-LRA XL-LRA RLA Y-D-LRA XL-LRA QTY
FLA LRA
MIN.
3, 5
MAX.
4, 6
BLOCK DISC SW. (EA.) (EA.)
380 467 600 500 600 (2) 1/0 - 300 (2) 250-500 121 285 900 121 285 900 8 5.1 21.0
0218EB 460 399 600 450 500 (2) 1/0 - 300 (2) 250-500 100 228 719 100 228 719 8 5.2 29.0
575 315 400 350 400 (2) # 2 - 4/0 (2) 3/0 - 250 80 182 574 80 182 574 8 3.9 25.9
380 582 600 700 800 (2) 2/0 - 500 (2) 250-500 121 285 900 213 343 1093 8 5.1 21.0
0248EB 460 493 600 600 700 (2) 1/0 - 300 (2) 250-500 100 228 719 176 280 893 8 5.2 29.0
575 391 600 450 600 (2) # 2 - 4/0 (2) 3/0 - 250 80 182 574 141 224 714 8 3.9 25.9
380 612 800 700 800 (2) 2/0 - 500 (3) 2/0 - 400 165 343 1093 165 343 1093 8 5.1 21.0
0268EB 460 519 600 600 700 (2) 2/0 - 500 (2) 250-500 137 280 893 137 280 893 8 5.2 29.0
575 410 600 450 500 (2) 1/0 - 300 (2) 250-500 109 224 714 109 224 714 8 3.9 25.9
380 671 800 800 1000 (2) 2/0 - 500 (3) 2/0 - 400 212 343 1093 166 343 1093 8 5.1 21.0
0288EB 460 568 600 700 800 (2) 2/0 - 500 (2) 250-500 176 280 893 137 280 893 8 5.2 29.0
575 450 600 500 600 (2) 1/0 - 300 (2) 250-500 141 224 714 109 224 714 8 3.9 25.9
380 689 800 800 1000 (3) 1/0 - 300 (3) 2/0 - 400 195 343 1093 166 343 1093 9 5.1 21.0
0308EB 460 584 800 700 800 (2) 2/0 - 500 (3) 2/0 - 400 161 280 893 137 280 893 9 5.2 29.0
575 462 600 500 600 (2) 1/0 - 300 (2) 250-500 129 224 714 109 224 714 9 3.9 25.9
380 707 800 800 1000 (3) 1/0 - 300 (3) 2/0 - 400 195 343 1093 184 343 1093 11 5.1 21.0
0328EB 460 599 800 700 800 (2) 2/0 - 500 (3) 2/0 - 400 161 280 893 152 280 893 11 5.2 29.0
575 475 600 500 600 (2) 1/0 - 300 (2) 250-500 129 224 714 122 224 714 11 3.9 25.9
380 799 1000 1000 1000 (3) 2/0 - 500 (4) 250-500 166 343 1093 166 343 1093 8 5.1 21.0
0358EB 460 680 800 800 1000 (2) 2/0 - 500 (3) 2/0 - 400 138 280 893 138 280 893 8 5.2 29.0
575 535 600 600 700 (2) 2/0 - 500 (3) 2/0 - 400 109 224 714 109 224 714 8 3.9 25.9
380 884 1000 1000 1200 (3) 2/0 - 500 (4) 250-500 194 343 1093 166 343 1093 9 5.1 21.0
0398EB 460 754 1000 800 1000 (3) 1/0 - 300 (3) 2/0 - 400 162 280 893 138 280 893 9 5.2 29.0
575 594 800 700 800 (2) 2/0 - 500 (3) 2/0 - 400 129 224 714 109 224 714 9 3.9 25.9
380 985 1000 1200 1200 (3) 2/0 - 500 (4) 250-500 196 343 1093 213 343 1093 9 5.1 21.0
0418EB 460 834 1000 1000 1000 (3) 2/0 - 500 (4) 250-500 162 280 893 176 280 893 9 5.2 29.0
575 661 800 700 800 (2) 2/0 - 500 (3) 2/0 - 400 129 224 714 141 224 714 9 3.9 25.9
See page 105 for Electrical Data footnotes.
OVER-CURRENT
PROTECTION
FIELD PROVIDED POWER SUPPLY
COMPRESSOR #1
