94
YORK INTERNATIONAL
95
YORK INTERNATIONAL
FORM 201.19-EG4
Electrical Data
MULTIPLE POINT POWER SUPPLY CONNECTION - 2 COMPRESSOR UNITS (SEE FIG. 1)
(Two Field Provided Power Supply Circuits To The Chiller. Field Connections to Factory Provided Terminal Block (Std), Disconnects (Opt),
or Individual System Circuit Breakers (Opt) in each of the two Motor Control Centers.)
SYSTEM #1 FIELD-SUPPLIED WIRING
MODEL
VOLTS
MIN NF
FACTORY PROVIDED (LUGS) WIRE RANGE
7
COMPRESSOR #1 FANS
11, 12
YCAS MCA
1
DISC SW
2, 9
STD. TERMINAL OPT. NF.
OPT. C.B. RLA Y-D-LRA XL-LRA QTY
FLA LRA
MIN.
3, 5
MAX.
4, 6
BLOCK DISC SW.
(EA.) (EA.)
200 235 250 300 400 1/0 - 300 #6 - 350 (2) 3/0 - 250 168 404 1257 3 8.2 33.0
230 206 200 250 350 1/0 - 300 #4 - 300 #6 - 350 146 354 1103 3 7.8 38.0
0098EB 380 125 150 150 200 # 2 - 1/0 * #4 - 300 #4 - 300 89 219 681 3 4.8 23.0
460 103 100 125 150 # 6 - 1/0 #14 - 1/0 #4 - 300 73 174 542 3 4.0 19.0
575 83 100 100 125 # 6 - 1/0 #14 - 1/0 #14 - 1/0 59 138 431 3 3.1 15.2
200 344 400 400 500 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 255 591 1866 3 8.2 33.0
230 301 400 350 500 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 222 481 1518 3 7.8 38.0
0118EB 380 182 200 225 300 # 2 - 4/0 #4 - 300 #4 - 300 134 285 900 3 4.8 23.0
460 151 150 200 250 # 2 - 4/0 #4 - 300 #4 - 300 111 228 719 3 4.0 19.0
575 121 150 150 200 # 6 - 1/0 #4 - 300 #4 - 300 90 182 574 3 3.1 15.2
200 324 400 400 500 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 233 591 1866 4 8.2 33.0
230 284 400 350 450 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 203 481 1518 4 7.8 38.0
0128EB 380 172 200 250 250 # 2 - 4/0 #4 - 300 #4 - 300 122 285 900 4 4.8 23.0
460 143 150 175 225 # 2 - 4/0 #4 - 300 #4 - 300 101 228 719 4 4.0 19.0
575 113 150 150 175 # 6 - 1/0 #4 - 300 #4 - 300 81 182 574 4 3.1 15.2
200 323 400 400 500 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 232 591 1866 4 8.2 33.0
230 284 400 350 450 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 202 481 1518 4 7.8 38.0
0138EB 380 172 200 225 250 # 2 - 4/0 #4 - 300 #4 - 300 122 285 900 4 4.8 23.0
460 142 150 175 225 # 2 - 4/0 #4 - 300 #4 - 300 101 228 719 4 4.0 19.0
575 113 150 150 175 # 6 - 1/0 #4 - 300 #4 - 300 81 182 574 4 3.1 15.2
200 324 400 400 500 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 233 591 1866 4 8.2 33.0
230 284 400 350 450 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 203 481 1518 4 7.8 38.0
0148EB 380 172 200 225 250 # 2 - 4/0 #4 - 300 #4 - 300 122 285 900 4 4.8 23.0
460 143 150 175 225 # 2 - 4/0 #4 - 300 #4 - 300 101 228 719 4 4.0 19.0
575 113 150 150 175 # 6 - 1/0 #4 - 300 #4 - 300 81 182 574 4 3.1 15.2
200 433 600 600 700 (2) 1/0 - 300 (3) 2/0 - 400 (3) 2/0 - 400 320 708 2256 4 8.2 33.0
230 379 400 450 600 (2) # 2-4/0 (2) 3/0 - 250 (3) 2/0 - 400 278 642 2045 4 7.8 38.0
0158EB 380 230 250 300 350 1/0 - 300 #6 - 350 (2) 3/0 - 250 168 343 1093 4 4.8 23.0
460 190 200 225 300 # 2 - 4/0 #4 - 300 #4 - 300 140 280 893 4 4.0 19.0
575 151 150 200 250 # 2 - 4/0 #4 - 300 #6 - 350 111 224 714 4 3.1 15.2
200 433 600 600 700 (2) 1/0 - 300 (3) 2/0 - 400 (3) 2/0 - 400 320 708 2256 4 8.2 33.0
230 378 400 450 600 (2) 1/0 - 300 (2) 3/0 - 250 (3) 2/0 - 400 278 642 2045 4 7.8 38.0
0178EB 380 230 250 300 350 1/0 - 300 #6 - 350 (2) 3/0 - 250 169 343 1093 4 4.8 23.0
460 191 200 225 300 # 2 - 4/0 #4 - 300 #4 - 300 140 280 893 4 4.0 19.0
575 151 150 200 250 # 2 - 4/0 #4 - 300 #6 - 350 111 224 714 4 3.1 15.2
200 510 600 600 800 (2) 2/0 - 500 (3) 2/0 - 400 (3) 2/0 - 400 375 708 2256 5 8.2 33.0
230 447 600 600 700 (2) 1/0 - 300 (3) 2/0 - 400 (3) 2/0 - 400 327 642 2045 5 7.8 38.0
0198EB 380 271 400 350 450 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 198 343 1093 5 4.8 23.0
460 225 250 300 350 1/0 - 300 #6 - 350 (2) 3/0 - 250 164 280 893 5 4.0 190.0
575 179 200 225 300 # 2 - 4/0 #6 - 350 #6 - 350 131 224 714 5 3.1 15.2
200 510 600 700 800 (2) 2/0 - 500 (3) 2/0 - 400 (3) 2/0 - 400 376 708 2256 5 8.2 33.0
230 447 600 600 700 (2) 1/0 - 300 (3) 2/0 - 400 (3) 2/0 - 400 326 642 2045 5 7.8 38.0
0208EB 380 271 250 350 450 2/0 - 500 #6 - 350 (2) 3/0 - 250 198 343 1093 5 4.8 23.0
460 225 250 300 350 1/0 - 300 #6 - 350 (2) 3/0 - 250 164 280 893 5 4.0 19.0
575 179 200 225 300 # 2 - 4/0 #6 - 350 #6 - 350 131 224 714 5 3.1 15.2
See page 105 for Electrical Data footnotes.
