FORM 201.19-EG4
SYSTEM #2 FIELD-SUPPLIED WIRING
MODEL
VOLTS MIN NF
FACTORY PROVIDED (LUGS) WIRE RANGE
7
COMPRESSOR #2 FANS
11, 12
YCAS MCA
1
DISC SW
2, 9
STD. TERMINAL OPT. NF.
OPT. C.B. RLA Y-D-LRA XL-LRA QTY
FLA LRA
MIN.
3, 5
MAX.
4, 6
BLOCK DISC SW.
(EA.) (EA.)
200 235 250 300 400 1/0 - 300 #6 - 350 (2) 3/0 - 250 168 404 1257 3 8.2 33.0
230 206 200 250 350 1/0 - 300 #4 - 300 #6 - 350 146 354 1103 3 7.8 38.0
0098EB 380 125 150 150 200 # 2 - 1/0 * #4 - 300 #4 - 300 89 219 681 3 4.8 23.0
460 103 100 125 150 # 6 - 1/0 #14 - 1/0 #4 - 300 73 174 542 3 4.0 19.0
575 83 100 100 125 # 6 - 1/0 #14 - 1/0 #14 - 1/0 59 138 431 3 3.1 15.2
200 234 250 300 400 1/0 - 300 #4 - 300 (2) 3/0 - 250 168 404 1257 3 8.2 33.0
230 206 200 250 350 1/0 - 300 #4 - 300 #6 - 350 146 354 1103 3 7.8 38.0
0118EB 380 125 150 150 200 # 6 - 1/0 #4 - 300 #4 - 300 88 219 681 3 4.8 23.0
460 103 100 125 150 # 6 - 1/0 #4 - 300 #4 - 300 73 174 542 3 4.0 19.0
575 83 100 100 125 # 6 - 1/0 #14 - 1/0 #14 - 1/0 59 138 431 3 3.1 15.2
200 232 250 300 350 1/0 - 300 #4 - 300 (2) 3/0 - 250 159 404 1257 4 8.2 33.0
230 205 200 250 300 1/0 - 300 #4 - 300 #6 - 350 139 354 1103 4 7.8 38.0
0128EB 380 124 150 150 200 # 6 - 1/0 #4 - 300 #4 - 300 84 219 681 4 4.8 23.0
460 102 100 125 150 # 6 - 1/0 #4 - 300 #4 - 300 69 174 542 4 4.0 19.0
575 82 100 100 125 # 6 - 1/0 #14 - 1/0 #14 - 1/0 56 138 431 4 3.1 15.2
200 323 400 400 500 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 232 591 1866 4 8.2 33.0
230 284 400 350 450 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 202 481 1518 4 7.8 38.0
0138EB 380 172 200 225 250 # 2 - 4/0 #4 - 300 #4 - 300 122 285 900 4 4.8 23.0
460 142 150 175 225 # 2 - 4/0 #4 - 300 #4 - 300 101 228 719 4 4.0 19.0
575 113 150 150 175 # 6 - 1/0 #4 - 300 #4 - 300 81 182 574 4 3.1 15.2
200 324 400 400 500 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 233 591 1866 4 8.2 33.0
230 284 400 350 450 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 203 481 1518 4 7.8 38.0
0148EB 380 172 200 225 250 # 2 - 4/0 #4 - 300 #4 - 300 122 285 900 4 4.8 23.0
460 143 150 175 225 # 2 - 4/0 #4 - 300 #4 - 300 101 228 719 4 4.0 19.0
575 113 150 150 175 # 6 - 1/0 #4 - 300 #4 - 300 81 182 574 4 3.1 15.2
200 324 400 400 500 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 233 591 1866 4 8.2 33.0
230 284 400 350 450 2/0 - 500 (2) 3/0 - 250 (2) 3/0 - 250 203 481 1518 4 7.8 38.0
0158EB 380 172 200 225 250 # 2 - 4/0 #6 - 350 #4 - 300 122 285 900 4 4.8 23.0
460 143 150 175 225 # 2 - 4/0 #4 - 300 #4 - 300 101 228 719 4 4.0 19.0
575 114 150 150 175 # 6 - 1/0 #4 - 300 #4 - 300 81 182 574 4 3.1 15.2
200 433 600 600 700 (2) 1/0 - 300 (3) 2/0 - 400 (3) 2/0 - 400 320 708 2256 4 8.2 33.0
230 378 400 450 600 (2) 1/0 - 300 (2) 3/0 - 250 (3) 2/0 - 400 278 642 2045 4 7.8 38.0
0178EB 380 230 250 300 350 1/0 - 300 #6 - 350 (2) 3/0 - 250 169 343 1093 4 4.8 23.0
460 191 200 225 300 # 2 - 4/0 #4 - 300 #4 - 300 140 280 893 4 4.0 19.0
575 151 150 200 250 # 2 - 4/0 #4 - 300 #6 - 350 111 224 714 4 3.1 15.2
200 412 400 500 700 (2) 2/0 - 300 (2) 3/0 - 250 (3) 2/0 - 400 297 708 2256 5 8.2 33.0
230 361 400 450 600 (2) # 2 - 4/0 (2) 3/0 - 250 (3) 2/0 - 400 258 642 2045 5 7.8 38.0
0198EB 380 219 250 300 350 1/0 - 300 (2) 3/0 - 500 (2) 3/0 - 250 156 343 1093 5 4.8 23.0
460 182 200 225 300 # 2 - 4/0 #6 - 350 #4 - 300 129 280 893 5 4.0 19.0
575 144 150 175 225 # 2 - 4/0 #6 - 350 #6 - 350 103 224 714 5 3.1 15.2
200 510 600 700 800 (2) 2/0 - 500 (3) 2/0 - 400 (3) 2/0 - 400 376 708 2256 5 8.2 33.0
230 447 600 600 700 (2) 1/0 - 300 (3) 2/0 - 400 (3) 2/0 - 400 326 642 2045 5 7.8 38.0
0208EB 380 271 250 350 450 2/0 - 500 #6 - 350 (2) 3/0 - 250 198 343 1093 5 4.8 23.0
460 225 250 300 350 1/0 - 300 #6 - 350 (2) 3/0 - 250 164 280 893 5 4.0 19.0
575 179 200 225 300 # 2 - 4/0 #6 - 350 #6 - 350 131 224 714 5 3.1 15.2
OVER-CURRENT
PROTECTION
FIELD PROVIDED POWER SUPPLY
