York R-407C Optimized - Page 18

18
YORK INTERNATIONAL
19
YORK INTERNATIONAL
FORM 201.19-EG4
Ratings – R-407C Optimized (English Units, continued)
LCWT
AIR TEMPERATURE ON CONDENSER (°F)
(°F)
75 80 85 90 95
TONS kW EER TONS kW EER TONS kW EER TONS kW EER TONS kW EER
MODEL YCAS0138EB (IPLV = 13.6)
40.0 134.0 103.7 13.6 129.6 110.9 12.4 125.2 118.6 11.3 120.8 126.9 10.3 116.5 135.8 9.3
42.0 138.5 104.1 14.0 134.1 111.5 12.8 129.6 119.1 11.7 125.1 127.4 10.6 120.7 136.2 9.6
44.0 143.0 104.5 14.4 138.7 111.8 13.2 134.1 119.5 12.0 129.5 127.7 10.9 126.8 136.8 10.1
45.0 145.2 104.7 14.6 141.0 112.0 13.4 136.3 119.7 12.2 131.7 127.9 11.1 127.2 136.8 10.1
46.0 147.5 104.9 14.8 143.3 112.1 13.6 138.6 119.9 12.4 133.9 128.1 11.3 129.3 136.9 10.3
48.0 152.0 105.2 15.3 147.8 112.4 14.0 143.2 120.2 12.8 138.4 128.5 11.6 133.7 137.3 10.6
50.0 156.5 105.5 15.7 152.4 112.8 14.4 147.8 120.5 13.1 142.9 128.8 12.0 138.2 137.6 10.9
52.0 161.0 105.8 16.1 157.0 113.0 14.8 152.5 120.8 13.5 147.5 129.1 12.3 142.7 137.9 11.2
55.0 168.5 106.1 16.8 164.0 113.4 15.4 159.5 121.2 14.1 154.5 129.5 12.9 149.6 138.3 11.8
MODEL YCAS0148EB (IPLV = 14.2)
40.0 140.9 104.3 14.2 136.0 111.5 13.0 131.1 119.2 11.8 126.3 127.5 10.7 121.7 136.3 9.7
42.0 145.5 104.7 14.7 140.7 111.9 13.4 135.7 119.6 12.1 130.8 127.9 11.0 126.1 136.7 10.0
44.0 150.2 105.1 15.1 145.4 112.3 13.8 140.3 120.0 12.5 135.3 128.2 11.4 130.5 137.0 10.3
45.0 152.5 105.3 15.3 147.7 112.4 14.0 142.6 120.2 12.7 137.6 128.4 11.6 132.7 137.2 10.5
46.0 154.9 105.4 15.5 150.1 112.6 14.2 145.0 120.3 12.9 139.9 128.6 11.7 134.9 137.3 10.7
48.0 159.5 105.7 15.9 154.9 112.9 14.6 149.7 120.6 13.3 144.5 128.9 12.1 139.5 137.7 11.0
50.0 164.5 105.9 16.4 159.7 113.2 15.0 154.4 120.9 13.7 149.2 129.2 12.5 144.0 138.0 11.3
52.0 169.6 106.1 16.9 164.4 113.4 15.4 159.3 121.2 14.1 153.9 129.5 12.8 148.7 138.3 11.7
55.0 177.0 106.6 17.6 171.6 113.7 16.1 166.5 121.6 14.7 161.1 129.9 13.4 155.7 138.7 12.2
MODEL YCAS0158EB (IPLV = 13.2)
40.0 157.3 124.6 13.6 151.8 133.0 12.4 146.4 142.2 11.2 141.1 152.0 10.2 135.9 162.5 9.2
42.0 162.4 125.4 13.9 156.9 133.8 12.7 151.4 142.9 11.5 146.0 152.7 10.5 140.7 163.2 9.5
44.0 167.6 126.0 14.3 162.1 134.5 13.1 156.4 143.6 11.9 150.9 153.4 10.8 145.5 163.8 9.8
45.0 170.2 126.3 14.5 164.6 134.8 13.2 159.0 143.9 12.1 153.4 153.7 11.0 148.0 164.1 9.9
46.0 172.8 126.6 14.7 167.2 135.2 13.4 161.5 144.2 12.2 155.9 154.1 11.1 151.1 164.6 10.1
48.0 178.2 127.2 15.1 172.5 135.8 13.8 166.7 144.8 12.6 161.0 154.6 11.4 155.4 165.0 10.4
50.0 183.5 127.7 15.5 177.7 136.3 14.1 171.9 145.5 12.9 166.1 155.2 11.8 160.4 165.6 10.7
52.0 189.0 128.2 15.9 183.0 136.9 14.5 177.2 146.1 13.2 171.2 155.9 12.1 165.5 166.2 11.0
55.0 197.3 129.1 16.5 191.0 137.7 15.1 185.1 147.0 13.8 179.0 156.8 12.5 173.1 167.3 11.4
NOTES:
1. kW = Compressor Input Power
2. EER = Chiller EER (includes power from compressors, fans, and control panels 0.8 kW)
3. LCWT = Leaving Chilled Water Temperature
4. Ratings based on 2.4 GPM cooler water per ton
5. Rated in accordance with ARI Standard 550/590-98
6. Shaded Ratings certied in accordance with ARI Standard 550/590-98 up to 200 tons.
