York TCHE24 User Manual

5371951-YTG-C-0919
10 Johnson Controls Ducted Systems
TCHE24S41S1 TM9E100C16MP11 21.0 CF/CM36D 650 24.0 17.7 15.75 13.00
TCHE24S41S1 TM9E100C16MP12 21.0 CF/CM/CU36C 800 24.0 18.9 16.00 13.00
TCHE24S41S1 TM9E100C16MP12 21.0 CF/CM/CU42C 800 24.0 18.8 16.00 13.00
TCHE24S41S1 TM9E100C16MP12 21.0 CF/CM30C 800 24.0 18.7 16.00 13.00
TCHE24S41S1 TM9E100C16MP12 21.0 CF/CM36D 800 24.0 18.9 16.00 13.00
TCHE24S41S1 TM9E100C16MP12 21.0 CF/CM42D 800 24.0 18.8 16.00 13.00
TCHE24S41S1 TM9E100C20MP11 21.0 CF/CM/CU30D 800 24.0 18.5 15.00 12.50
TCHE24S41S1 TM9E100C20MP11 21.0 CF/CM/CU36C 800 24.0 18.6 15.00 12.50
TCHE24S41S1 TM9E100C20MP11 21.0 CF/CM30C 800 24.0 18.5 15.00 12.50
TCHE24S41S1 TM9E100C20MP11 21.0 CF/CM36D 800 24.0 18.6 15.00 12.50
TCHE24S41S1 TM9E120D20MP11 24.5 CF/CM/CU30D 825 24.0 18.6 15.25 12.75
TCHE24S41S1 TM9E120D20MP11 24.5 CF/CM36D 825 24.0 19.1 15.25 12.75
TCHE24S41S1 TM9V040A10MP12C 14.5 CF/CM/CU30A 625 23.6 16.8 15.00 12.50
TCHE24S41S1 TM9V040A10MP12C 14.5 CF/CM/CU30B 625 23.8 17.0 15.00 12.50
TCHE24S41S1 TM9V040A10MP12C 14.5 CF/CM/CU36B 650 24.0 17.7 15.25 12.50
TCHE24S41S1 TM9V040A10MP12C 14.5 CF/CM36A 650 23.8 17.5 15.00 12.50
TCHE24S41S1 TM9V060B12MP11C 17.5 CF/CM/CU30B 800 24.0 18.5 15.25 12.75
TCHE24S41S1 TM9V060B12MP11C 17.5 CF/CM/CU36B 825 24.0 19.1 15.50 12.75
TCHE24S41S1 TM9V060B12MP12C 17.5 CF/CM/CU30B 700 24.0 18.0 15.50 12.75
TCHE24S41S1 TM9V060B12MP12C 17.5 CF/CM/CU36B 700 24.0 18.0 15.50 12.75
TCHE24S41S1 TM9V060B12MP12C 17.5 CF/CM/CU36C 700 24.0 17.9 15.50 12.75
TCHE24S41S1 TM9V060B12MP12C 17.5 CF/CM30C 700 24.0 17.9 15.50 12.75
TCHE24S41S1 TM9V080B12MP11C 17.5 CF/CM/CU30B 800 24.0 18.5 15.25 12.75
TCHE24S41S1 TM9V080B12MP11C 17.5 CF/CM/CU36B 825 24.0 19.1 15.50 12.75
TCHE24S41S1 TM9V080B12MP11C 17.5 CF/CM/CU36C 850 24.0 19.4 15.75 13.00
TCHE24S41S1 TM9V080B12MP11C 17.5 CF/CM30C 725 24.0 18.1 15.75 13.00
TCHE24S41S1 TM9V080B12MP12C 17.5 CF/CM/CU30B 800 24.0 18.7 15.75 13.00
TCHE24S41S1 TM9V080B12MP12C 17.5 CF/CM/CU36B 800 24.0 19.0 15.75 13.00
TCHE24S41S1 TM9V080B12MP12C 17.5 CF/CM/CU36C 850 24.0 19.4 15.75 13.00
TCHE24S41S1 TM9V080B12MP12C 17.5 CF/CM30C 725 24.0 18.1 15.75 13.00
TCHE24S41S1 TM9V080C16MP11C 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S1 TM9V080C16MP11C 21.0 CF/CM/CU36C 850 24.0 19.1 15.50 12.75
TCHE24S41S1 TM9V080C16MP12C 21.0 CF/CM/CU36C 950 24.0 20.4 15.75 13.00
TCHE24S41S1 TM9V080C16MP12C 21.0 CF/CM30C 950 24.0 20.0 15.75 13.00
TCHE24S41S1 TM9V080C16MP12C 21.0 CF/CM36D 950 24.0 20.4 16.00 13.00
TCHE24S41S1 TM9V100C16MP11C 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S1 TM9V100C16MP11C 21.0 CF/CM/CU36C 850 24.0 19.1 15.50 12.75
TCHE24S41S1 TM9V100C16MP11C 21.0 CF/CM30C 850 24.0 19.0 15.50 12.75
TCHE24S41S1 TM9V100C16MP11C 21.0 CF/CM30C 900 24.0 19.5 16.00 13.00
TCHE24S41S1 TM9V100C16MP11C 21.0 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TM9V100C16MP11C 21.0 CF/CM36D 900 24.0 19.7 16.00 13.00
TCHE24S41S1 TM9V100C16MP12C 21.0 CF/CM/CU30C 900 24.0 19.7 15.50 12.75
TCHE24S41S1 TM9V100C16MP12C 21.0 CF/CM/CU30D 900 24.0 19.7 15.75 13.00
TCHE24S41S1 TM9V100C16MP12C 21.0 CF/CM/CU36C 900 24.0 19.7 16.00 13.00
TCHE24S41S1 TM9V100C16MP12C 21.0 CF/CM/CU36D 900 24.0 19.8 16.00 13.00
TCHE24S41S1 TM9V100C16MP12C 21.0 CF/CM30C 900 24.0 19.5 16.00 13.00
TCHE24S41S1 TM9V100C16MP12C 21.0 CF/CM36D 900 24.0 19.7 16.00 13.00
TCHE24S41S1 TM9Y040A10MP11 14.5 CF/CM/CU30A 675 23.8 17.5 14.75 12.25
TCHE24S41S1 TM9Y040A10MP11 14.5 CF/CM/CU30B 700 24.0 17.9 14.75 12.50
TCHE24S41S1 TM9Y040A10MP11 14.5 CF/CM/CU36B 700 24.0 18.0 15.00 12.50
TCHE24S41S1 TM9Y040A10MP11 14.5 CF/CM36A 675 23.8 17.6 14.75 12.25
TCHE24S41S1 TM9Y060B12MP11 17.5 CF/CM/CU30B 675 24.0 17.6 15.50 12.75
TCHE24S41S1 TM9Y060B12MP11 17.5 CF/CM/CU36B 675 24.0 17.8 15.50 12.75
COOLING CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.

York TCHE24 Specifications
