York TCHE24 User Manual

5371951-YTG-C-0919
6 Johnson Controls Ducted Systems
— = Not Applicable.
MP Modular Air Handlers use Coil Only Ratings.
PSC furnaces, such as the TG8S, TGLS, and TG9S, use Coil Only Ratings.
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL
CFM RANGE
(MIN.-MAX.)
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER
1
EER
TOTAL SENS.
TCHE24S41S1 CF/CM/CU30A 14.5 600 - 1000 800 24.0 18.6 14.00 12.20
TCHE24S41S1 CF/CM/CU30B 17.5 600 - 1000 800 24.0 17.5 14.00 12.20
TCHE24S41S1 CF/CM/CU36B 17.5 600 - 1000 800 24.0 18.9 14.00 12.20
TCHE24S41S1 CF/CM/CU36C 21.0 600 - 1000 800 24.0 18.9 14.00 12.20
TCHE24S41S1 CF/CM30C 21.0 600 - 1000 800 24.0 18.6 14.00 12.20
TCHE24S41S1 CF/CM36A 14.5 600 - 1000 800 24.0 18.9 14.00 12.20
TCHE24S41S1 CF/CM36D 24.5 600 - 1000 800 24.0 18.9 14.00 12.20
TCHE36S41S1 FC38C 21.0 1000 - 1400 1200 35.6 27.2 14.00 12.20
TCHE48S41S1 FC49D 21.0 1400 - 1800 1425 46.0 33.8 14.00 12.15
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.
1. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60 second time delay.
COOLING CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
TCHE24S41S1 TL8E060A12UH11 14.5 CF/CM/CU30A 650 24.0 17.4 15.50 12.75
TCHE24S41S1 TL8E060A12UH11 14.5 CF/CM/CU30B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TL8E060A12UH11 14.5 CF/CM/CU36B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TL8E060A12UH11 14.5 CF/CM36A 625 24.0 17.2 15.75 13.00
TCHE24S41S1 TL8E060A12UH11 14.5 CF42B 675 24.0 17.6 15.75 13.00
TCHE24S41S1 TL8E080C16UH11 21.0 CF/CM30C 950 24.0 20.0 16.00 13.00
TCHE24S41S1 TL9E060B12UH11 17.5 CF/CM/CU30B 675 24.0 17.7 15.50 12.75
TCHE24S41S1 TL9E060B12UH11 17.5 CF/CM/CU36B 650 24.0 17.6 15.75 13.00
TCHE24S41S1 TL9E060B12UH11 17.5 CF/CM/CU36C 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TL9E060B12UH11 17.5 CF/CM/CU42C 700 24.0 17.8 15.75 13.00
TCHE24S41S1 TL9E060B12UH11 17.5 CF/CM30C 700 24.0 17.9 15.50 12.75
TCHE24S41S1 TL9E060B12UH11 17.5 CF42B 675 24.0 17.7 15.75 13.00
TCHE24S41S1 TL9E080C16UH11 21.0 CF/CM/CU36C 925 24.0 19.8 16.00 13.00
TCHE24S41S1 TL9E080C16UH11 21.0 CF/CM/CU42C 925 24.0 19.7 16.00 13.00
TCHE24S41S1 TL9E080C16UH11 21.0 CF/CM30C 925 24.0 19.8 16.00 13.00
TCHE24S41S1 TL9E080C16UH11 21.0 CF/CM36D 925 24.0 19.8 16.00 13.00
TCHE24S41S1 TL9E080C16UH11 21.0 CF/CM42D 925 24.0 19.7 16.00 13.00
TCHE24S41S1 TM8E040A12MP11 14.5 CF/CM/CU30A 725 24.0 18.2 15.50 12.75
TCHE24S41S1 TM8E040A12MP11 14.5 CF/CM/CU30B 775 24.0 18.5 15.75 13.00
TCHE24S41S1 TM8E040A12MP11 14.5 CF/CM/CU36B 775 24.0 18.8 16.00 13.00
TCHE24S41S1 TM8E040A12MP11 14.5 CF/CM36A 725 24.0 18.3 15.75 13.00
TCHE24S41S1 TM8E040A12MP11 14.5 CF42B 775 24.0 18.7 16.00 13.00
TCHE24S41S1 TM8E060A12MP11 14.5 CF/CM/CU30A 725 24.0 18.2 15.50 12.75
TCHE24S41S1 TM8E060A12MP11 14.5 CF/CM/CU30B 750 24.0 18.3 15.75 13.00
TCHE24S41S1 TM8E060A12MP11 14.5 CF/CM/CU36B 825 24.0 19.1 15.75 13.00
TCHE24S41S1 TM8E060A12MP11 14.5 CF/CM36A 725 24.0 18.3 15.75 13.00
TCHE24S41S1 TM8E060A12MP11 14.5 CF42B 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TM8E080B12MP11 17.5 CF/CM/CU30B 725 24.0 18.1 15.75 13.00
TCHE24S41S1 TM8E080B12MP11 17.5 CF/CM/CU36B 725 24.0 18.3 16.00 13.00
TCHE24S41S1 TM8E080B12MP11 17.5 CF/CM/CU36C 750 24.0 18.3 15.75 13.00
TCHE24S41S1 TM8E080B12MP11 17.5 CF/CM/CU42C 750 24.0 18.4 16.00 13.00
TCHE24S41S1 TM8E080B12MP11 17.5 CF/CM30C 750 24.0 18.3 15.75 13.00
TCHE24S41S1 TM8E080B12MP11 17.5 CF42B 725 24.0 18.0 16.00 13.00
TCHE24S41S1 TM8E080C16MP11 21.0 CF/CM/CU36C 825 24.0 19.1 16.00 13.00
