York TCHE24 User Manual

5371951-YTG-C-0919
Johnson Controls Ducted Systems 5
— = Not applicable.
MP Modular Air Handlers use Coil Only Ratings.
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
TCHE24S41S1 AE30BX21 17.5 – 900 24.00 19.50 16.00 13.00
TCHE24S41S1 AE36BX21 17.5 – 850 24.00 19.40 16.00 13.00
TCHE24S41S1 AE36CX21 21.0 – 800 24.00 18.90 16.00 13.00
TCHE24S41S1 AHE30B3X(H,T)21 17.5 – 795 24.00 18.30 15.50 12.75
TCHE24S41S1 AHE36C3X(H,T)21 21.0 – 855 24.00 18.80 15.75 13.00
TCHE24S41S1 AHV30B3X(H,T)21 17.5 – 775 24.00 18.20 15.50 12.75
TCHE24S41S1 AHV36C3X(H,T)21 21.0 – 760 24.00 17.90 15.75 13.00
TCHE24S41S1 AP30BX21 17.5 – 850 24.00 19.40 14.00 12.25
TCHE24S41S1 AVC30BX21 17.5 – 750 24.00 18.30 16.00 13.00
TCHE24S41S1 AVC36BX21 17.5 – 750 24.00 18.30 16.00 13.00
TCHE24S41S1 AVC36CX21 21.0 – 875 24.00 19.70 16.00 13.00
TCHE24S41S1 ME08BN21 17.5 CF/CM30B 800 24.00 18.70 16.00 13.00
TCHE24S41S1 ME08BN21 17.5 CF/CM36B 800 24.00 18.90 16.00 13.00
TCHE24S41S1 ME12BN21 17.5 CF/CM30B 875 24.00 19.20 16.00 13.00
TCHE24S41S1 ME12BN21 17.5 CF/CM36B 875 24.00 19.70 16.00 13.00
TCHE24S41S1 ME12CN21 21.0 CF/CM30C 850 24.00 19.30 16.00 13.00
TCHE24S41S1 ME12CN21 21.0 CF/CM36C 850 24.00 19.40 16.00 13.00
TCHE24S41S1 ME14DN21 24.5 CF/CM36D 875 24.00 19.70 16.00 13.00
TCHE24S41S1 ME16CN21 21.0 CF/CM30C 925 24.00 19.80 16.00 13.00
TCHE24S41S1 ME16CN21 21.0 CF/CM36C 925 24.00 19.80 16.00 13.00
TCHE24S41S1 MV12BN21 17.5 FC/MC35B 800 24.00 18.40 15.75 13.00
TCHE24S41S1 MV12BN21 17.5 FC/MC36B 800 24.00 18.20 15.75 13.00
TCHE24S41S1 MV12BN21 17.5 FC/MC42B 800 24.00 18.00 15.75 13.00
TCHE24S41S1 MV12BN21 17.5 FC/MC43B 800 24.00 18.20 15.75 13.00
TCHE24S41S1 MVC08BN21 17.5 CF/CM30B 800 24.00 18.70 16.00 13.00
TCHE24S41S1 MVC08BN21 17.5 CF/CM36B 800 24.00 18.90 16.00 13.00
TCHE24S41S1 MVC12BN21 17.5 CF/CM30B 875 24.00 19.20 16.00 13.00
TCHE24S41S1 MVC12BN21 17.5 CF/CM36B 875 24.00 19.60 16.00 13.00
TCHE24S41S1 MVC12CN21 21.0 CF/CM30C 875 24.00 19.30 16.00 13.00
TCHE24S41S1 MVC12CN21 21.0 CF/CM36C 875 24.00 19.70 16.00 13.00
TCHE24S41S1 MVC16CN21 21.0 CF/CM30C 925 24.00 19.80 16.00 13.00
TCHE24S41S1 MVC16CN21 21.0 CF/CM36C 925 24.00 19.80 16.00 13.00
TCHE24S41S1 MX12BN21 17.5 FC/MC35B 800 24.00 18.40 15.50 12.75
TCHE24S41S1 MX12BN21 17.5 FC/MC36B 800 24.00 18.20 15.75 13.00
TCHE24S41S1 MX12BN21 17.5 FC/MC43B 800 24.00 18.20 15.50 12.75
TCHE24S41S1 MX16CN21 21.0 FC/MC35C 800 24.00 18.40 15.25 12.75
TCHE24S41S1 MX16CN21 21.0 FC/MC36C 800 24.00 18.20 15.25 12.75
TCHE24S41S1 MX16CN21 21.0 FC/MC43C 800 24.00 18.20 15.25 12.75
TCHE36S41S1 ME16CN21 21.0 FC38C 1200 36.00 27.20 16.00 13.00
TCHE36S41S1 MVC16CN21 21.0 FC38C 1200 35.80 27.20 15.50 12.75
TCHE48S41S1 ME14DN21 24.5 FC49D 1425 46.50 34.60 15.10 12.50
TCHE48S41S1 ME20DN21 24.5 FC49D 1425 46.50 34.60 15.50 12.50
TCHE48S41S1 MVC14DN21 24.5 FC49D 1175 45.50 31.80 15.50 12.75
TCHE48S41S1 MVC20DN21 24.5 FC49D 1375 46.50 34.20 15.50 12.75
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total
electric power input in watt-hours during the same period.
1. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.
