Natural Gas LP Gas (Requires LP conversion kit)
LP Conversion Kit Installed By
Supply static after evaporator coil (in w.c.")
Return Static (in w.c.") before filter
Total External Static Pressure
Temperature rise in degrees F measured in low fire
Installation debris disposed of and furnace area cleaned up?
Explain operation of system to equipment owner
Low Heat Blower Speed Selected
Red (Low) Yel (Med Low) Blue (Med/Med High)
Black (High)
Explain the importance of regular filter replacement and equipment maintenance
Gas Side
Air Side: System External Static Pressure
Owner Education
Supply static before evaporator coil (in w.c.")
Calculated input in btuh - clock the gas meter in high fire (Nat Gas Only)
Low Fire Manifold Gas Pressure (in. w.c.")Inlet Gas Pressure (in. w.c.")
LP Gas Conversion Kit Part # Used
Burner flame inspected -- flames are blue and extending directly into the primary heat exchanger cells
Return Static (in w.c.") after filter (furnace side)
Air Side: Heating (PSC)
Air Side: Cooling (PSC)
Air Side: Continuous Fan (PSC)
Clean Up
Give owner the owner's manual provided
Gas Type
Explain thermostat use and programming (if applicable) to owner
Cycle Test
Operate the furnace through several heating cycles from the thermostat, noting and correcting any problems
Operate the furnace through continuous fan cycles from the thermostat, noting and correcting any problems
Operate the furnace through cooling cycles (as applicable), noting and correcting any problems
High Heat Blower Speed Selected
Red (Low) Yel (Med Low) Blue (Med/Med High)
Black (High)
Blower Speed Selected
Lo Heat HI Heat Lo Cool
Hi Cool
High Fire Manifold Gas Pressure (in. w.c.")
Temperature rise in degrees F measured in Low fire
Heat Speed Selected
Air Side: Heating (Variable Speed ECM)
A B
C
D
Temperature rise in degrees F measured in high fire
Other Jumpers
De-humidistat
Yes No
Heat Pump
Yes No
Low Cool Blower Speed Selected
Red (Low) Yel (Med Low) Blue (Med/Med High)
Black (High)
High Cool Blower Speed Selected
Red (Low) Yel (Med Low) Blue (Med/Med High)
Black (High)
Air Side: Cooling (Variable Speed ECM)
COOL Speed Selected
A
B
C
D
ADJUST Setting
A
B
C
D
DELAY Setting
A
B
C
D
Air Side: Continuous Fan (Variable Speed ECM)
Blower (5-Speed) Selected
Lo Cool HI Cool Hi Heat Lo HeatLo Heat VSG
Blower (3-Speed) Selected
L (Low) M (Med) H (High)
Temperature rise in degrees F measured in high fire
Cooling CFM delivery (use Blower Performance Data Chart)
Hi Low
