628792-BTG-G-0418
Ducted Systems 15
Weight And Dimensions
Corner Weights & Center Of Gravity (Inches)
Unit Model
Unit Weight (Lbs.)
Unit Dimensions
(Inches)
A B C D Dim X Dim Y
Weight
A to B
Weight
D to C
Shipping Operation Length Width
YJ-30 1875 1895 128.5 88.5 404 537 533 401 55.2 44.1 934 941
YJ-40 2315 2347 128.5 88.5 486 675 671 483 53.8 44.1 1154 1161
YJ-50 2345 2381 128.5 88.5 486 693 685 481 53.0 44.0 1166 1179
Corner Weights & Center Of Gravity
