York YLUA Series User Manual

24 JOHNSON CONTROLS
FORM 150.63-EG4 (1012)
Physical Data
Refrigerant R-410A
Model Number YLUA
HIGH EFFICIENCY UNITS
0248YE 0278YE 0298YE 0308YE 0338YE 0408YE 0468YE 0498YE
General Unit Data
Length (mm)
2948.9 2948.9 2948.9 3624.6 3624.6 3624.6 4767.6 4767.6
Width (mm)
2235.2 2235.2 2235.2 2235.2 2235.2 2235.2 2235.2 2235.2
Height (mm)
2392.7 2392.7 2392.7 2392.7 2392.7 2392.7 2392.7 2392.7
Refrigerant
Number of Refrigerant Circuits
2 2 2 2 2 2 2 2
Refrigerant Charge Circuit 1 (kg.)
24.5 25.4 25.4 35.4 25.4 36.7 36.7 49
Refrigerant Charge Circuit 2 (kg.)
22.2 22.2 23.1 33.1 44.5 34.5 34.5 43.5
Oil Charge, ckt1, (l.)
9.8 12.4 12.4 10.4 12.4 12.6 18.9 18.9
Oil Charge, ckt2, (l.)
9.8 9.8 10.4 10.4 12.6 12.6 10.4 12.6
Shipping Weight (kg.)
1684.2 1809.4 1898.3 2227.6 2334.2 2368.2 2936.1 3006.4
Compressors, scroll type
Compressors per circuit 3/3 3/3 3/2 2/2 3/2 2/2 3/2 3/2
Compressors per unit 6 6 5 4 5 4 5 5
Nominal Tons per compressor
Circuit 1
45.7 52.7 52.7 52.7/112.5 52.7 112.5 112.5 112.5
Circuit 2
45.7 45.7 52.7/112.5 52.7/112.5 112.5 112.5 52.7/112.5 112.5
Condenser
Total Face Area m2
9.9 9.9 9.9 14.9 14.9 14.9 19.9 19.9
Number of Rows
3 3 3 3 3 3 3 3
Fins per mm
1 1 1 1 1 1 1 1
Condenser Fans, Low Sound
Number of Fans, ckt1./ckt2. 2/2 2/2 2/2 3/3 2/4 3/3 4/4 4/4
Fan hp
1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
Total Chiller CFM
24541.3 24541.3 24541.3 36811.9 36811.9 36811.9 49082.5 49082.5
