York YLUA Series User Manual

FORM 150.63-EG4 (1012)
25JOHNSON CONTROLS
New Model
Length Width Height Connection Sizes
L W H F P Suction In 1 / 2 Liquid Out 1 / 2 Suction In Liquid Out Suction In Liquid Out
YLAA0248YE
116.1 88.3 95.3 89.7 43.9 2.7 1.1 39.6 17 17 84.3
YLAA0278YE
116.1 88.3 95.3 89.7 43.9 2.7 1.1 39.6 17 17 84.3
YLAA0298YE
116.1 88.3 95.3 89.7 43.9 2.7 1.1 39.6 17 17 84.3
System 1 Dimensions System 2 Dimensions
New Model
Isolator Location Dimensions Rigging Hole Locations
D2 I1 I2 I3 I4 I5 I6 I7 I8 A B R1 R2 R3 R4
YLAA0248YE
35.5 19.5 76.6 1.3 85.5 23.2 68.3
YLAA0278YE
35.5 19.5 76.6 1.3 85.5 23.2 68.3
YLAA0298YE
35.5 18.5 76.6 1.3 85.5 23.2 68.3
Dimension Drawings
