York YLUA Series User Manual

26 JOHNSON CONTROLS
FORM 150.63-EG4 (1012)
New Model
Length Width Height Connection Sizes
L W H F P Suction In Liquid Out Suction In Liquid Out
YLUA0308YE 143.5 88.3 95.3 89.7 43.9 2.7 1.1 41 26.9 26.9 84.4
YLUA0338YE 143.5 88.3 95.3 89.7 43.9 2.7 1.1 41
-17.1 26.9 84.4
YLUA0408YE 143.5 88.3 95.3 89.7 43.9 2.7 1.1 41 26.9 26.9 84.4
System 1 Dimensions System 2 Dimensions
Suction In 1 /
2
Liquid Out 1 /
2
New Model
Isolator Location Dimensions Rigging Hole Locations
D2 I1 I2 I3 I4 I5 I6 I7 I8 A B R1 R2 R3 R4
YLAA0308YE
35.5 7.6 117.2 1.4 85.5 23.2 95.9
YLAA0338YE
35.5 7.6 117.2 1.4 85.5 23.2 95.9
YLAA0408YE
35.5 7.6 117.2 1.4 85.5 23.2 95.9
Dimension Drawings - continued
L2-OUT
S2-IN
