036-21570-002 Rev. D (0605)
18 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
OUTDOOR UNIT MODEL NO. YMA03011
INDOOR COIL MODEL NO. G2FD030S17
AIR TEMP.
ENTERING
OUTDOOR
UNIT
AIR TEMP.
ENTERING
INDOOR
COIL
ID CFM
800 1000 1200
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 37.8 2.9 3.8 37.2 2.9 3.8 36.6 2.8 3.9
70 36.1 3.1 3.5 35.9 3.0 3.5 35.8 2.9 3.6
80 34.5 3.2 3.2 34.7 3.1 3.3 34.9 3.0 3.4
47
60 33.5 2.7 3.7 33.1 2.6 3.7 32.7 2.5 3.8
70 28.6 2.7 3.1 30.0 2.7 3.3 31.4 2.6 3.5
80 23.6 2.8 2.5 26.9 2.7 2.9 30.1 2.7 3.2
40
60 29.2 2.5 3.4 29.5 2.5 3.5 29.8 2.4 3.6
70 27.4 2.6 3.1 27.8 2.5 3.2 28.2 2.5 3.3
80 25.5 2.6 2.9 26.0 2.6 2.9 26.6 2.6 3.0
30
60 25.1 2.3 3.2 25.4 2.3 3.3 25.7 2.3 3.3
70 23.2 2.3 2.9 23.6 2.3 3.0 24.0 2.3 3.0
80 21.2 2.4 2.6 21.8 2.4 2.7 22.3 2.4 2.8
17
60 19.6 2.1 2.7 19.9 2.1 2.8 20.2 2.1 2.9
70 17.2 2.2 2.3 17.8 2.1 2.4 18.4 2.1 2.5
80 14.9 2.2 2.0 15.7 2.2 2.1 16.5 2.2 2.2
10
60 16.4 2.1 2.3 16.7 2.1 2.4 17.1 2.0 2.4
70 14.5 2.1 2.0 14.9 2.1 2.1 15.3 2.1 2.2
80 12.7 2.1 1.8 13.1 2.1 1.8 13.6 2.1 1.9
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil
MBH KW COP
F2RC/F2FC036 1.00 1.01 0.99
F2RP/F2FP/F3FP030 1.00 1.01 0.99
N1AHB08 G2FD030(S,H)17(T) 1.00 1.00 1.00
N1AHB12 G2FD030(S,H)17(T) 1.00 1.00 1.00
N1VSB12 G2FD030(S,H)17(T) 0.98 1.05 0.93
G1FA036S14 1.00 1.00 1.00
G1FA036S17,21 1.00 1.00 1.00
G2FD030(S,H)17(T) 1.00 1.00 1.00
G2FD035(S,H)14(T) 1.00 1.00 1.00
G1NA036S17J 1.00 1.00 1.00
G1NA036S21C 1.00 1.00 1.00
G1HD036 1.01 1.03 0.98
G1HA036H14 0.99 0.98 1.01
G1HA036H17 0.99 1.01 0.99
Variable Speed
Furnace
Coil
T.C. S.C. KW
P*DUB16V G1FA036S17 0.98 1.04 0.94
P*DUA12V G1FA036S14 0.98 1.04 0.95
P*DUB16V G1FA036S17 0.98 1.04 0.94
P*DUB16V G2FD030(S,H)17(T) 0.98 1.04 0.94
P*DUC20V G1FA036S21 0.97 1.05 0.93
P1XUB12V G1FA036S17 0.99 1.04 0.95
P1XUB12V G2FD030(S,H)17(T) 0.99 1.04 0.95
P1XUC16V G1FA036S21 0.97 1.05 0.93
P1XUC20V G1FA036S21 0.97 1.05 0.93
P1XDB12V G2FD030(S,H)17(T) 0.98 1.03 0.95
P1XDB12V G1HA036H17 0.97 1.05 0.95
