York YMA024 - Page 19

036-21570-002 Rev. D (0605)
Unitary Products Group 19
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
OUTDOOR UNIT MODEL NO. YMA03611
INDOOR COIL MODEL NO. G2FD036S17
AIR TEMP.
ENTERING
OUTDOOR
UNIT
AIR TEMP.
ENTERING
INDOOR
COIL
ID CFM
1000 1200 1400
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 41.2 3.0 4.0 42.8 2.9 4.3 44.4 2.9 4.6
70 38.4 3.2 3.5 39.8 3.1 3.8 41.3 3.0 4.0
80 35.6 3.3 3.1 36.9 3.3 3.3 38.1 3.2 3.5
47
60 37.0 2.8 3.8 38.1 2.8 4.0 39.1 2.7 4.3
70 34.0 3.0 3.3 35.2 2.9 3.5 36.4 2.8 3.7
80 31.0 3.1 2.9 32.3 3.1 3.1 33.7 3.0 3.3
40
60 34.2 2.7 3.7 35.7 2.7 3.9 37.3 2.6 4.2
70 31.2 2.8 3.2 32.6 2.8 3.4 34.1 2.8 3.6
80 28.3 3.0 2.8 29.6 2.9 3.0 30.9 2.9 3.1
30
60 30.2 2.6 3.4 31.2 2.6 3.6 32.2 2.5 3.8
70 27.7 2.7 3.0 28.6 2.7 3.2 29.4 2.6 3.3
80 25.2 2.8 2.6 25.9 2.7 2.8 26.6 2.7 2.9
17
60 20.0 2.4 2.4 20.9 2.4 2.6 21.9 2.4 2.7
70 20.3 2.4 2.4 21.0 2.4 2.5 21.7 2.4 2.6
80 20.6 2.5 2.4 21.1 2.5 2.5 21.6 2.5 2.6
10
60 23.1 2.3 3.0 23.9 2.3 3.1 24.7 2.2 3.2
70 20.7 2.3 2.6 21.1 2.3 2.7 21.4 2.3 2.7
80 18.3 2.4 2.3 18.2 2.4 2.3 18.2 2.3 2.3
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil
MBH KW COP
F2RP/F2FP/F3FP036 0.99 0.99 0.99
F2FP/F3FP040 0.99 1.00 0.99
F2RP/F2FP/F3FP042 0.99 1.00 0.99
N1VSB12 G2FD036(S,H)17(T) 0.99 1.05 0.95
N1VSC16 G2FD036(S,H)21(T) 0.99 1.06 0.93
N1AHB08 G2FD036(S,H)17(T) 1.00 1.00 1.00
N1AHB12 G2FD036(S,H)17(T) 1.00 1.00 1.00
N1AHC16 G2FD036(S,H)21(T) 1.00 1.00 1.00
G1FA036S14(T) 1.00 1.00 1.00
G1FA036S17,21(T) 0.98 0.97 1.01
G2FD036(S,H)17(T) 1.00 1.00 1.00
G2FD036(S,H)21(T) 1.00 1.00 1.00
G1NA036S17J 0.98 0.97 1.01
G1NA036S21C 0.98 0.97 1.01
G1HD036 0.99 1.00 0.99
G1HA036H14(T) 0.98 0.97 1.01
G1HA036H17(T) 0.98 0.97 1.01
Variable Speed
Furnace
Coil
T.C. S.C. KW
P*DUA12V G1FA036S14(T) 0.99 1.02 0.97
P*DUB16V G1FA036S17(T) 0.97 1.01 0.96
P*DUB16V G2FD036(S,H)17(T) 0.98 1.04 0.95
P*DUC20V G1FA036S21(T) 0.97 1.02 0.96
P*DUC20V G2FD036(S,H)21(T) 0.98 1.05 0.94
P1XUB12V G1FA036S17(T) 0.98 1.00 0.98
P1XUB12V G2FD036(S,H)17(T) 0.99 1.02 0.97
P1XUC16V G1FA036S21(T) 0.97 1.01 0.96
P1XUC16V G2FD036(S,H)21(T) 0.98 1.05 0.94
P1XUC20V G1FA036S21(T) 0.97 1.02 0.96
P1XUC20V G2FD036(S,H)21(T) 0.98 1.05 0.94
P1XDB12V G2FD036(S,H)17(T) 0.99 1.02 0.97
P1XDB12V G1HA036H17(T) 0.98 1.00 0.98
P1XDC20V G2FD036(S,H)21(T) 0.98 1.02 0.96
