York ZF SERIES Installation Manual

5725848-XIM-A-0319
Johnson Controls Ducted Systems 27
CONDENSER FAN DATA
Quantity
1 1 11
Fan diameter (Inch)
24 24 24 24
Type
Prop Prop Prop Prop
Drive type
Direct Direct Direct Direct
Quantity of motors
1 1 11
Motor HP each
1/2 1/2 1/2 3/4
No. speeds
1 1 11/2
RPM
910 910 910 910
Nominal total CFM
- - - -
BELT DRIVE EVAP FAN DATA
Quantity
- - 11
Fan Size (Inch)
- - 12 x 10 12 x 11
Type
- - Centrifugal Centrifugal
Motor Sheave - - 1VL44 IVM50
Blower Sheave - - AK54 AK56
Belt - - A35 A36
Motor HP each - - 1-1/2 1-1/2
RPM
- - 1450 1450
Frame size
- - 56 56
DIRECT DRIVE EVAP FAN DATA
Quantity
1 1 --
Fan Size (Inch)
12 x 10 12 x 10 --
Type
Centrifugal Centrifugal --
Motor HP each
1/2 1 --
RPM
1050 1050 --
FILTERS
15” x 20” x 1” or 2”
2 2 22
14” x 25” x 1” or 2”
1 1 11
Table 10: ZF036-076 physical data (continued)
Component
Models
ZF036 ZF048 ZF060 ZF076
Nominal Tonnage 3.0 4.0 5.0 6.3
