York ZF SERIES Installation Manual

5725848-XIM-A-0319
Johnson Controls Ducted Systems 31
Figure 18: Unit dimensions (rear view)
mm[inch]
445
[17
1
/
2
]
445
[17
1
/
2
]
165
[6
1
/
2
]
292
[11
1
/
2
]
76 [3]
200
[7
7
/
8
]
117 [4
5
/
8
]
292
[11
1
/
2
]
Figure 19: Disconnect/blower access location
Table 14: Utilities entry
HOLE
OPENING SIZE (DIA.)
(mm/in)
USED FOR
A
22 / 0.88 KO
1
Control Wiring
2
Side
Bottom
B
51 / 2.0 KO
1
Power Wiring
Side
Bottom
C
41 / 1.63 KO Gas Piping (Front)
D
38 / 1.5 KO
Gas Piping (Bottom)
1. Opening in the bottom to the unit can be located by the
side in the insulation.
2. Do not remove the 2” knockout ring.
Disconnect Switch Location
and Motor Access Panel for
Unit with “Belt-Drive” Option
Control Box Access
A,B
Wiring Entry
(See Detail “B”)
Mounting Bracket for
Disconnect Switch
(Field Supplied)
Field-Supplied Disconnect
Switch Location
Blower Motor Access
Filter Access
Dot Plugs
Table 15: Minimum clearances
LOCATION
CLEARANCE (mm / In.)
Front
610 / 24.0 (Cooling/Electric Heat)
813 / 32.0 (Gas Heat)
Back
305 / 12.0 (Less Economizer)
914 / 36.0 (With Economizer or
Fixed Air/Motorized Damper)
Left Side (Filter Access)
610 / 24.0 (Less Economizer)
914 / 36.0 (With Economizer)
Right Side (Cond. Coil)
610 / 24.0
Below Unit
1
0
Above Unit
2
1829 / 72.0 (For
Condenser Air Discharge)
1. Units may be installed on combustible floors made from
wood or class A, B, or C roof covering material.
2. Units must be installed outdoors. Overhanging struc-
tures or shrubs should not obstruct condenser air dis-
charge outlet.
