5725848-XIM-A-0319
Johnson Controls Ducted Systems 33
Table 17: Supply air blower performance (5 ton belt drive) - side duct application
M
3
/S
UNIT
TONNAGE
AIR
FLOW
M
3
/S
AVAILABLE EXTERNAL STATIC PRESSURE-Pa*
50 74 99 124 149 174 198
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
5
1
1.18 1059 1560 1077 1590 1095 1630 1114 1650 1134 1660 1158 1685 - -
1.13 1032 1405 1054 1470 1074 1525 1094 1560 1116 1595 1140 1620 1167 1640
1.08 1005 1260 1024 1275 1049 1370 1069 1440 1090 1475 1116 1505 1142 1535
1.04 980 1160 1002 1170 1022 1190 1044 1250 1066 1350 1090 1410 1117 1440
0.99 930 1060 957 1070 983 1080 1010 1100 1039 1160 1064 1260 1092 1340
0.94 877 950 908 975 941 1000 976 1020 1009 1050 1040 1100 1070 1225
0.90 - - - - 894 885 940 940 980 980 1014 1020 1047 1095
0.85 - - - - 855 815 903 860 950 905 988 940 1022 970
0.80 - - - - - - 884 815 925 850 964 880 1001 910
0.75 - - - - - - 864 770 908 805 948 835 987 870
0.71 --------882740926780965830
UNIT
TONNAGE
AIR
FLOW
M
3
/S
AVAILABLE EXTERNAL STATIC PRESSURE-Pa*
223 248 273 298 322 347 372
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
5
1
1.18 --------------
1.13 --------------
1.0811701580------------
1.04 1148 1480 1180 1530 - - - - - - - - - -
0.99 1121 1385 1155 1425 - - - - - - - - - -
0.94 1100 1285 1133 1340 1169 1385 - - - - - - - -
0.90 1079 1180 1110 1240 1143 1280 1178 1330 - - - - - -
0.85 1058 1060 1090 1135 1122 1190 1158 1240 - - - - - -
0.80 1035 960 1071 1030 1103 1100 1134 1140 1164 1175 - - - -
0.75 1020 900 1056 965 1088 1035 1118 1065 1145 1105 1170 1130 - -
0.71 1004 860 1038 880 1070 925 1101 980 1130 1045 1158 1075 - -
CFM
UNIT
TONNAGE
AIR
FLOW
CFM
AVAILABLE EXTERNAL STATIC PRESSURE-IWG*
0.20 0.30 0.40 0.50 0.60 0.70 0.80
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
5
1
2500 1059 1560 1077 1590 1095 1630 1114 1650 1134 1660 1158 1685 - -
2400 1032 1405 1054 1470 1074 1525 1094 1560 1116 1595 1140 1620 1167 1640
2300 1005 1260 1024 1275 1049 1370 1069 1440 1090 1475 1116 1505 1142 1535
2200 980 1160 1002 1170 1022 1190 1044 1250 1066 1350 1090 1410 1117 1440
2100 930 1060 957 1070 983 1080 1010 1100 1039 1160 1064 1260 1092 1340
2000 877 950 908 975 941 1000 976 1020 1009 1050 1040 1100 1070 1225
1900 - - - - 894 885 940 940 980 980 1014 1020 1047 1095
1800 - - - - 855 815 903 860 950 905 988 940 1022 970
1700 - - - - - - 884 815 925 850 964 880 1001 910
1600 - - - - - - 864 770 908 805 948 835 987 870
1500 - - - - - - - - 882 740 926 780 965 830
UNIT
TONNAGE
AIR
FLOW
CFM
AVAILABLE EXTERNAL STATIC PRESSURE-IWG*
0.90 1.00 1.10 1.20 1.30 1.40 1.50
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
5
1
2500--------------
2400--------------
230011701580------------
2200 1148 1480 1180 1530 - - - - - - - - - -
2100 1121 1385 1155 1425 - - - - - - - - - -
2000 1100 1285 1133 1340 1169 1385 - - - - - - - -
1900 1079 1180 1110 1240 1143 1280 1178 1330 - - - - - -
1800 1058 1060 1090 1135 1122 1190 1158 1240 - - - - - -
1700 1035 960 1071 1030 1103 1100 1134 1140 1164 1175 - - - -
1600 1020 900 1056 965 1088 1035 1118 1065 1145 1105 1170 1130 - -
1500 1004 860 1038 880 1070 925 1101 980 1130 1045 1158 1075 - -
1. Side Duct application (380/415 Volts)
*Includes allowances for a wet evaporator coil, 25mm [1 in] filters, and the heat exchangers. Refer to STATIC RESISTANCES Table
for resistance values on applications other than gas/electric units with side duct airflows.
