York ZF SERIES Installation Manual

5725848-XIM-A-0319
26 Johnson Controls Ducted Systems
Table 10: ZF036-076 physical data
Component
Models
ZF036 ZF048 ZF060 ZF076
Nominal Tonnage 3.0 4.0 5.0 6.3
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu)
36400 51472 60400 72600
ARI net capacity (Btu)
35200 49635 57800 69100
EER (Net)
11.5 11.8 11.5 10.9
SEER
13.0 14.0 13.0 -
Nominal CFM
1200 1600 2000 2500
System power (KW)
4.2 4.1 4.9 6.3
Refrigerant type
R-410A R-410A R-410A R-410A
Refrigerant charge (lb-oz)
System 1 4-12 5-2 5-4 6-8
ARI HEATING PERFORMANCE
Heating model
H05 H07 H10 H10
Heat input (K Btu)
50 75 100 100
Heat output (K Btu)
40 60 80 80
AFUE %
80.9 80.9 80.5 80.5
Steady state efficiency (%)
- - --
No. burners
2 3 44
No. stages
1 1 11
Temperature Rise Range (ºF) 15-45 25-70 25-55 25-55
Gas Limit Setting (ºF) - Direct Drive 240 210 - -
Gas Limit Setting (ºF) - Belt Drive - - 210 210
Gas piping connecting (in.)
1/2 1/2 1/2 1/2
DIMENSIONS (inches)
Length
82 1/4 82 1/4 82 1/4 82 1/4
Width
44 7/8 44 7/8 44 7/8 44 7/8
Height
32 5/8 32 5/8 32 5/8 32 5/8
OPERATING WT. (lbs.)
468 515 569 640
COMPRESSORS
Type
Recip Scroll Scroll Scroll
Quantity
1 1 11
Unit Capacity Steps (%)
100 100 100 100
CONDENSER COIL DATA
Face area (Sq. Ft.) 16.3 16.3 16.3 16.3
Rows
1 1 11
Fins per inch
23 23 23 23
Tube diameter (in./mm)
0.71 / 18 0.71 / 18 0.71 / 18 1.0 / 25.4
Circuitry Type
2-pass
Microchannel
2-pass
Microchannel
2-pass
Microchannel
2-pass
Microchannel
EVAPORATOR COIL DATA
Face area (Sq. Ft.)
5.06 5.06 5.06 5.06
Rows
3 4 44
Fins per inch
13 13 13 13
Tube diameter
0.375 0.375 0.375 0.375
Circuitry Type
Intertwined Intertwined Intertwined Intertwined
Refrigerant control
Fixed Orifice Fixed Orifice Fixed Orifice Fixed Orifice
