5725848-XIM-A-0319
28 Johnson Controls Ducted Systems
Table 11: Electrical data ZF036-076
Model Power Supply
Compressors (each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Electric Heat Option
MCA
1
(Amps)
1. Minimum Circuit Ampacity.
Max Fuse /
BRKR
2
Siz e
(Amps)
2. HACR Type per NEC.
RLA LRA MCC FLA FLA Model
3, 4
3. These electric heaters DO NOT include a fuse box. If required to meet local code, the fuse block accessory 2FB04700546 is available for
field installation.
4. Heaters are suitable for operation on 380/415-3-50 power supply
KW Stages Amps
ZF036
380-3-50 4.8 35 7.5 1.3 2.5
NONE - - - 9.8 15
2EH04510746 4.3 1 6.5 11.3 15
2EH04511046 6.3 1 9.6 15.1 20
2EH04511546 8.5 2 12.9 19.3 20
2EH04512046 12.2 2 18.5 26.3 30
415-3-50 4.8 35 7.5 1.3 2.5
NONE - - - 9.8 15
2EH04510746 5.1 1 7.1 12 15
2EH04511046 7.5 1 10.4 16.2 20
2EH04511546 10.2 2 14.2 20.9 25
2EH04512046 14.6 2 20.3 28.5 30
ZF048
380-3-50 7.8 47 12.1 1.3 4.24
NONE - - - 15.3 20
2EH04510746 4.3 1 6.5 15.3 20
2EH04511046 6.3 1 9.6 18.2 20
2EH04511546 8.5 2 12.9 22.3 25
2EH04512046 12.2 2 18.5 29.4 30
415-3-50 7.8 51.5 12.1 1.3 4.24
NONE - - - 15.3 20
2EH04510746 5.1 1 7.1 15.3 20
2EH04511046 7.5 1 10.4 19.2 20
2EH04511546 10.2 2 14.2 23.9 25
2EH04512046 14.6 2 20.3 31.6 35
ZF060
380-3-50 8 67.1 12.5 1.3 2.7
NONE - - - 14 20
2EH04510746 4.3 1 6.5 14 20
2EH04511046 6.3 1 9.6 15.3 20
2EH04511546 8.5 2 12.9 19.5 20
2EH04512046 12.2 2 18.5 26.5 30
2EH04513046 18.1 2 27.5 37.8 40
415-3-50 8 67.1 12.5 1.3 2.7
NONE - - - 14 20
2EH04510746 5.1 1 7.1 14 20
2EH04511046 7.5 1 10.4 16.4 20
2EH04511546 10.2 2 14.2 21.1 25
2EH04512046 14.6 2 20.3 28.8 30
2EH04513046 21.5 2 29.9 40.8 45
ZF076
380-3-50 11.2 75 17.5 2.03 2.7
NONE - - - 18.7 25
2EH04510746 4.3 1 6.5 18.7 25
2EH04511046 6.3 1 9.6 18.7 25
2EH04511546 8.5 2 12.9 19.5 25
2EH04512046 12.2 2 18.5 26.5 30
2EH04513046 18.1 2 27.5 37.8 40
415-3-50 11.2 75 17.5 2.03 2.7
NONE - - - 18.7 25
2EH04510746 5.1 1 7.1 18.7 25
2EH04511046 7.5 1 10.4 18.7 25
2EH04511546 10.2 2 14.2 21.1 25
2EH04512046 14.6 2 20.3 28.8 30
2EH04513046 21.5 2 29.9 40.8 45
Table 12: Electric heat correction factors
NOMINAL VOLT-
AGE
VOLTAGE
kW CAP. MULTI-
PLIER
380
380 0.627
415
415 0.75
Table 13: Voltage limitations
POWER SUPPLY
VOLTAGE
MIN. MAX.
380/415-3-50
342 456
