White Hot Fulgurite Iron Red Hot Iron Medical Artic Rainbow1
Rainbow2 Tint Black Hot
2. Thermography Video
The Real time video from the E20Tvx displayed on the screen.
3. Measuring area and Temperature indication
The Temperature measure area or spot sight bead, the number in the red rectangle
show the measure result.
The following shows the different sight bead in different ROI mode
ROI mode: Area ROI mode: Spot
In Spot ROI mode, users can measure the temperature of a specified point by
tapping on the thermography area directly.
4. Gimbal attitude indicator (Tilt and Pan)
The Position of the Yellow dot in the gimbal tilt indicator bar shows the gimbal
tilt attitude. The red marks in the bar shows the gimbal is tilted up meanwhile the
green marks shows the gimbal is tilted down. For further accuracy, we can read the
gimbal tilt angle in the rectangle under the Vertical bar.
