YUNEEC H850 - Safety Settings (Continued); Max Vertical and Horizontal Velocity; Attachment - Specification; T1 Transmitter Specifications

Max Vertical and Horizontal Velocity setting
Tap the box for each items then type in the parameters to set the max climb, descent and
horizontal velocity.
Notice: We do not suggest the operator to change these parameters for flight safety.
Attachment
Specification
T1 Transmitter
Operating System
Android
Flight Control Software
DataPilot 2.0 App
Operating Frequency
2.400 - 2.4835 GHz
5.725 – 5.850 GHz
Transmission Protocol
2.4GHz & 5GHz
Transmission Power (EIRP)
2.4 GHz :
CE<18dBm FCC <29dBm
5 GHz :
CE<12dBm FCC <22dBm
Max Transmitting Distance
(unobstructed, free of interference)
CE: 8km
FCC: 10km
Video Output Ports
HDMI
OSD Supported
Yes
Built-in Screen Size
7”
Video Link Resolution
720P
Operating Temperature
-20℃-50℃
-4° F -122° F
Battery
7.4V 10000mAh
74Wh Li-ion
USB Supply Power
5V
