OPERATING ＆ INSTALLATION
Ⅰ. FEATURE VIEW
※Nebulizing
outlet
(7F-5AW)
OPERATING ＆ INSTALLATION
Ⅱ. PREPARE WORK
Do not use extended
power line.
Screw securely to the
bottle back clockwise.
Close the transparent door.
Plug in: First confirm the
power switch of oxygen
concentrator is off, then
connect the plug.
Open the transparent door, unscrew the bottle from the
humidifier counter-clockwise. Fill the bottle with pure water
(or distilled water) to the level indicated by the
manufacturer.
Oxygen outlet
Oxygen inlet
Safety valve
(on the inside)
Cover
Tube
Ⅲ. OXYGEN ABSORBING OPERATION
Turn the power switch to " | ", the LCD shows "HELLO" ,
Green, yellow, red indicator all light indicates that the
machine is normal. The green indicator lights only 1 second
later. 4 seconds later, the LCD shows elapsed time and time
setting interface then the machine goes to normal operation.
Figure 5
2
The MINIMUM
water level
The MAXIMUM
water level
Figure 4
Figure 3
