yy-electron.inc 7
Activating Your Portable Keypad.
With your system in programming status(see page 5), push
button 【 study 6 4 # 】on
Keypad Controller , and then
enter into the
Portable Keypad
: 【 1 2 3 4 # 1 】. You will
hear two beeping sounds indicating that your Portable Keypad is
now activated. Push EXIT to complete the process.
See page 16 for Portable Keypad operation.
Activating Your Panic Button
With your system in programming status
(see page 5) , push button
【 study 6 4 # 】on keypad controller , and then push button on
your Panic Button. You will hear two beeping sounds indicating that your
panic button is now activated. Push button EXIT to complete the process
Note: Program motion detectors first before programming other components. After programming each
motion detector turn its power switch to “off” [turn pet immune motion detectors face down]. After
programming all of the other components then turn the motion detectors back on.
Each individual sensor (Motion detector, window/door sensor, smoking/gas detector.....) has to be individually
activated while unit is in “programming status” (see page 5).
This system is unique in letting you know exactly which sensor is setting off the alarm. Each sensor is
programmed to have its own numerical identity. To perform this activation programming, you first assign a
two digit numbers to each sensor. Window/door sensors may be assigned any number between 09 and 63;
motion detectors for any number between 01 and 05, smoke, gas detector & glass break detector for any
number between 06 and 08. These are zone numbers. You may assign up to three sensors to the same zone.
When a sensor is triggered the assigned zone number will light up on the LED screen of the keypad. It may be
helpful for you to keep a list of the areas corresponding to the assigned zones
