Z-EDGE R1 User Manual

-10-
3 Using the Car Dash Camera
3.1 Recording Videos
3.2 Recording Screen
With an SD card inserted and the device connected to power, when the car engine is
switched on, the dashcam automatically powers on and starts recording. When the
vehicle engine is switched off, the dashcam will automatically save the recording and
power off within 10 seconds.
Alternatively, short press the 'OK
' button (11) to stop/start video recording manually.
While the dash camera is recording
1. Record 7. Protect Video
2. Resolution 8. Snapshot
3. WDR 9. Audio Recording
4. Parking Mode 10. Stop
5. Audio Recording Status 11. Date Time
6. Wi-Fi 12. Battery
Record
2020/04/20 11:53:00
P
1080P
WDR
1 2 3 4 5
6
7
8
9
10
1112

Z-EDGE R1 Specifications

General

Brand	Z-EDGE
Model	R1
Category	Dash Cameras
Language	English
