Z-EDGE R1 User Manual

-21-
Item Description
Image Sensor
Resolution
Storage Media
LED Display
Lens
Still Image (Photo Mode)
ISO
White Balance
Microphone
Speaker
Interface
Battery
Operating Temperature
Operating Humidity
Storage Temperature
Dimensions
Weight
Car Charger
CMOS sensor IMX307+GC2053
1296+1080P 30FPS
Supports Micro SD, up to 256GB Class 10 or above
2.7"TFT LCD 960*240
Wide Angle Fixed Focus lens F1.8(front) 140 Degrees,
F2.1(rear) 110 Degrees
Sensor Resolution: 2M Format: JPEG
Auto
Auto
Yes
Yes
Micro USB 2.0
Built-in Li-polymer rechargeable
(This battery is NOT replaceable)
14° ~ 158° F
20 ~ 70% RH
-4° ~ 158° F
3.5 x 2 x 1.2 inch, 89 x 52 x 32 mm (LxWxH)
3.0oz/85g
INPUT: DC 12-24V, OUTPUT: DC 5V 1A
9 Product Specifications

Z-EDGE R1 Specifications

General

Brand	Z-EDGE
Model	R1
Category	Dash Cameras
Language	English
