Zagg Limitless - Packed - Including Packing; Detachability of Cable Pull out; Key Board Specification; Life Test

3855 South 500 West Ste Q | Salt Lake City, Ut | 84115 | 801.506.7081
6
Parts
Material Color Texture
Cover, Bottom, HF-3201GS
PC
White/Black
Bottom side: See CMF
Bezel, Keys, HF-3201GS PC White/Black MT 11010 Texture
Top Cover, PC White/Black
MT 11010 Texture on the perimeter with a
High gloss finish around the keys
Small Bottom Cover PC White/Black High Gloss Finish
Rubber Foot
Rubber
50A
Black
Cradle PC Black Rubberized Paint
2.2 Packed - Including Packing
Product Dimensions Tolerance: +/- 3 mm
Package Spec. Qty Width Length Height Weight
Gift box with handle
1 19 cm 30 cm 2.8 cm 693 grams
Carton (Inner) 5 30.5 cm 15 cm 21 cm 3.75 KGS
Carton (Outer)
10 32.5 cm 32 cm 23.8 cm 8.26 KGS
2.3 Detachability of Cable Pull Out
The cable entrance for corded devices can meet product specification. Function
test will be performed before and after this test. Refer to the definition of related
standard.
USB Implementers Forum. 2007-01-04. Micro USB connector mating force is less
than 30N, un-mating force is 8+/-1N. Life test is 5000 cycles in this device.
2.4 Key Board Specification
2.4.1 Life Test
Standard key is 5 million cycles and Function key is 3 million cycles. (5
times/second, 65±8gf).
2.4.2 Max Keycap Depressing Force
