9
E: Small Key
Key in Force (Center)
≥
80g
2.5 Characteristics of Switches
2.5.1 Slide Switch
No slide switch
2.5.2 Tact Switch
No tact switch
2.5.3 Sleep Magnet Function
No Sleep Magnet.
2.6 Characteristics of Cradle
2.6.1 Cradle Dimensions
Cradle is 274 mm long, 12 mm wide, and 11 mm deep on the inside slot
dimensions. The wall thickness will be approximately 1.8mm.
2.6.2 Cradle Material
The material for the cradle will be a hard plastic like PC or ABS. Then coated with
a rubberized paint to give it a soft feel. We are evaluating a foam insert to
accommodate different thicknesses of devices. The material will also have a
