Zanussi ZITN320X User Manual

BUILDING IN
min. 2 mm
A
B
A
12 mm
28 mm
38 mm
B
57 mm
41 mm
31 mm
min
30 mm
min. 500 mm
< 20 mm
> 20 mm
min. 2 mm
A
B
A
12 mm
28 mm
38 mm
B
57 mm
41 mm
31 mm
min. 500 mm
270
+1
mm
R 5mm
min.
55mm
490
+1
mm
A
Place the sealing gasket A all around the edge of
the cut out.
Fit the hob in the cut out and push it down until
comes in contact with the kitchen top surface. then
remove the excess sealing.
6
