zapco Reference 1000.4 - Reference 1100.1 Specifications

43
Reference 1100.1 Specifications
Total Power (14.4V @ 1kHz) Power
Dynamic (4Ω mono)
1450 Watts
Rated Power T.H.D.+N
825 watts x 1@ 4Ω
< .03%
1100watts x 1 @ 2Ω
< .05%
Frequency Response 20 – 20kHz, + 0 / - .5dB
S/N Ratio > 90dB
Transient Distortion (4Ω, 40W)
< .03%
Slew Rate
40 V/µS
Damping Factor
> 700 @ 4Ω
Input Sensitivity
Balanced (DIN) 250mV – 10V
Max. Current Requirements 135 Amps @ 900 watts
Idle Current 1.5 Amps
Dimensions 23”L x 7.5”W x 1.95”H
