zapco Reference 650.6 - Reference 200.2 Specifications

23
Reference 200.2 Specifications
Total Power (14.4V @ 1kHz) Power
Dynamic (4Ω mono)
230 watts
.2% T.H.D. 205 watts
Rated Power / Channel T.H.D.+N
50 watts x 2 @ 4Ω
< .025%
100 watts x 2 @ 2Ω
< .14%
Bridged Mono
134 watts x 1 @ 8Ω
.046% T.H.D.
205 watts x 1 @ 4Ω
.12% T.H.D.
Frequency Response
20 – 20kHz, ± .12dB
S/N Ratio > 95dB
Transient Distortion (4Ω, 40W)
< .01%
Slew Rate
> 23 V/µS
Damping Factor
> 166 @ 4Ω
Input Sensitivity
Balanced (DIN) 500mV – 10V
Unbalanced (RCA) 250mV – 5V
Separation > 64dB
Max. Current Requirements 26 Amps @ 200 watts
Idle Current .84 Amps
Dimensions 11”L x 7.5”W x 1.95”H
