zapco Reference Series 2 User Manual

39
Reference 500.1 Specifications
Total Power (14.4V @ 1kHz)
.2% T.H.D. 500 watts
Rated Power T.H.D.+N
350 watts x 1 @ 4Ω
< .04%
500 watts x 1@ 2Ω
< .20%
Frequency Response 20 – 20kHz, +0/-.5dB
S/N Ratio > 80dB
Transient Distortion (4Ω, 35W)
< .013%
Slew Rate
> 25 V/µS
Damping Factor
> 250 @ 4Ω
Input Sensitivity
Balanced (DIN) 250mV – 10V
Max. Current Requirements 40 Amps @ 500 watts
Idle Current .65 Amps
Dimensions 12”L x 7.5”W x 1.95”H

zapco Reference Series 2 Specifications

General

Brand	zapco
Model	Reference Series 2
Category	Amplifier
Language	English
